WAGO 2022-101/000-012 1-Pole 1-Conductor Female Plug, Push-in CAGE CLAMP®, 2.5 mm², Orange
Wago
$2.24
1-conductor female connector; Push-in CAGE CLAMP; 4 mm²; Pin spacing 5.2 mm; 1-pole; 4,00 mm²; orange.
The WAGO component equivalent to 2022101000012 is a specific part or module used in electrical or automation systems. It is designed to perform a particular function within a larger system, ensuring compatibility and seamless integration with other components. This component is likely part of WAGO's extensive range of products known for their reliability and efficiency in various industrial applications.
- actuation type:
- Operating tool || Push-in
- approvals per:
- C22.2 No 158
- color:
- Orange
- connectable conductor materials:
- Copper
- connection technology:
- Push-in CAGE CLAMP
- connector connection type:
- For conductor
- contact type pluggable connector:
- Female connector/socket
- country of origin sales organisation germany:
- DE
- depth:
- 22.4 mm / 0.882 inch
- fine stranded conductor:
- 0.25 4 mm / 22 12 AWG
- fine stranded conductor with ferrule push in termination:
- 1 2.5 mm / 18 14 AWG
- fine stranded conductor with insulated ferrule:
- 0.25 2.5 mm / 22 14 AWG
- fire load:
- 0.060 MJ
- flammability class per ul94:
- V0
- height:
- 40.5 mm / 1.594 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- marking level:
- Side marking
- module width:
- 5.2 mm / 0.205 inch
- nominal cross section:
- 2.5 mm
- nominal voltage iii 3:
- 690 V
- note conductor cross section:
- Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
- packaging type:
- Box
- pole no:
- 1
- rated current:
- 24 A
- rated current 2:
- 32 A
- rated current csa use group c:
- 20 A
- rated current ul use group b:
- 20 A
- rated current ul use group c:
- 20 A
- rated surge voltage iii 3:
- 6 kV
- rated voltage ul use group b:
- 600 V
- rated voltage ul use group c:
- 600 V
- ratings per:
- IEC/EN 61984
- safety information 1:
- According to EN 61984, pluggable connectors without current interrupting capacity must not be mated or unmated when live or under load.
- solid conductor:
- 0.25 4 mm / 22 12 AWG
- solid conductor push in termination:
- 0.75 4 mm / 18 12 AWG
- strip length:
- 10 12 mm / 0.39 0.47 inch
- weight:
- 3.400 g
- width:
- 5.2 mm / 0.205 inch
- wiring direction:
- Front-entry wiring
