Wago 2022-101/000-016

WAGO 2022-101/000-016 1-conductor female plug; 1-pole; 2,50 mm²; green-yellow

Wago
SKU:
51201198
$2.15
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
1-conductor female connector; Push-in CAGE CLAMP; 4 mm²; Pin spacing 5.2 mm; 1-pole; 4,00 mm²; green-yellow.

The WAGO 2022 X-COM S series plug features a 5.2mm pin spacing and is designed for protective-earth (PE) connections for 2.5mm² wires. It supports a rated current of 24A and comes in a green-yellow color. The plug utilizes Push-in CAGE CLAMP spring connections and is suitable for plug-in mounting with a 5.2mm width, equivalent to part number 2022101000016.

Additional Information
actuation type:
Operating tool || Push-in
color:
Green-yellow
connectable conductor materials:
Copper
connection technology:
Push-in CAGE CLAMP
connector connection type:
For conductor
contact type pluggable connector:
Female connector/socket
country of origin sales organisation germany:
DE
depth:
22.4 mm / 0.882 inch
fine stranded conductor:
0.25 4 mm / 22 12 AWG
fine stranded conductor with ferrule push in termination:
1 2.5 mm / 18 14 AWG
fine stranded conductor with insulated ferrule:
0.25 2.5 mm / 22 14 AWG
fire load:
0.060 MJ
flammability class per ul94:
V0
height:
40.5 mm / 1.594 inch
insulation material:
Polyamide (PA66)
marking level:
Side marking
module width:
5.2 mm / 0.205 inch
nominal cross section:
2.5 mm
note conductor cross section:
Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
packaging type:
Box
pole no:
1
ratings per:
IEC/EN 61984
safety information 1:
According to EN 61984, pluggable connectors without current interrupting capacity must not be mated or unmated when live or under load.
solid conductor:
0.25 4 mm / 22 12 AWG
solid conductor push in termination:
0.75 4 mm / 18 12 AWG
strip length:
10 12 mm / 0.39 0.47 inch
weight:
3.415 g
width:
5.2 mm / 0.205 inch
wiring direction:
Front-entry wiring
