WAGO 2022-103/000-006 3-position female terminal block plug
Wago
$5.35
1-conductor female connector; Push-in CAGE CLAMP; 4 mm²; Pin spacing 5.2 mm; 3-pole; 4,00 mm²; blue.
The WAGO component, equivalent to 2022103000006, is a specific part or module used in various applications, likely within electrical or automation systems. This component is designed to meet certain specifications and standards, ensuring compatibility and functionality within its intended use. It may be part of a larger system or assembly, contributing to the overall performance and reliability of the equipment it is integrated into.
- actuation type:
- Operating tool || Push-in
- approvals per:
- C22.2 No 158
- color:
- Blue
- connectable conductor materials:
- Copper
- connection technology:
- Push-in CAGE CLAMP
- connector connection type:
- For conductor
- contact type pluggable connector:
- Female connector/socket
- country of origin sales organisation germany:
- DE
- depth:
- 22.4 mm / 0.882 inch
- fine stranded conductor:
- 0.25 4 mm / 22 12 AWG
- fine stranded conductor with ferrule push in termination:
- 1 2.5 mm / 18 14 AWG
- fine stranded conductor with insulated ferrule:
- 0.25 2.5 mm / 22 14 AWG
- fire load:
- 0.166 MJ
- flammability class per ul94:
- V0
- height:
- 40.5 mm / 1.594 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- marking level:
- Side marking
- module width:
- 5.2 mm / 0.205 inch
- nominal cross section:
- 2.5 mm
- nominal voltage iii 3:
- 690 V
- note conductor cross section:
- Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
- packaging type:
- Box
- pole no:
- 3
- rated current:
- 24 A
- rated current 2:
- 32 A
- rated current csa use group c:
- 20 A
- rated current ul use group b:
- 20 A
- rated current ul use group c:
- 20 A
- rated surge voltage iii 3:
- 6 kV
- rated voltage csa use group c:
- 600 V
- rated voltage ul use group b:
- 600 V
- rated voltage ul use group c:
- 600 V
- ratings per:
- IEC/EN 61984
- safety information 1:
- According to EN 61984, pluggable connectors without current interrupting capacity must not be mated or unmated when live or under load.
- solid conductor:
- 0.25 4 mm / 22 12 AWG
- solid conductor push in termination:
- 0.75 4 mm / 18 12 AWG
- strip length:
- 10 12 mm / 0.39 0.47 inch
- weight:
- 9.885 g
- width:
- 15.6 mm / 0.614 inch
- wiring direction:
- Front-entry wiring
