WAGO 2022-109/000-012 9-Pole 1-Conductor Female Connector CAGECLAMP 4mm² Orange
Wago
$14.62
1-conductor female connector; Push-in CAGE CLAMP; 4 mm²; Pin spacing 5.2 mm; 9-pole; 4,00 mm²; orange.
The WAGO component equivalent to 2022109000012 is a specific part or module used in electrical and automation systems. It is designed to meet the same specifications and performance criteria as the original component, ensuring compatibility and reliability in various applications. This equivalence allows for seamless integration and replacement in existing systems, maintaining operational efficiency and reducing downtime.
- actuation type:
- Operating tool || Push-in
- approvals per:
- UL 1059
- color:
- Orange
- connectable conductor materials:
- Copper
- connection technology:
- Push-in CAGE CLAMP
- connector connection type:
- For conductor
- contact type pluggable connector:
- Female connector/socket
- country of origin sales organisation germany:
- DE
- depth:
- 22.4 mm / 0.882 inch
- fine stranded conductor:
- 0.25 4 mm / 22 12 AWG
- fine stranded conductor with ferrule push in termination:
- 1 2.5 mm / 18 14 AWG
- fine stranded conductor with insulated ferrule:
- 0.25 2.5 mm / 22 14 AWG
- fire load:
- 0.484 MJ
- flammability class per ul94:
- V0
- height:
- 40.5 mm / 1.594 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- marking level:
- Side marking
- module width:
- 5.2 mm / 0.205 inch
- nominal cross section:
- 2.5 mm
- nominal voltage iii 3:
- 690 V
- note conductor cross section:
- Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
- packaging type:
- Box
- pole no:
- 9
- rated current:
- 24 A
- rated current 2:
- 32 A
- rated current csa use group c:
- 20 A
- rated current ul use group b:
- 20 A
- rated current ul use group c:
- 20 A
- rated surge voltage iii 3:
- 6 kV
- rated voltage csa use group c:
- 600 V
- rated voltage ul use group b:
- 600 V
- rated voltage ul use group c:
- 600 V
- ratings per:
- IEC/EN 61984
- safety information 1:
- According to EN 61984, pluggable connectors without current interrupting capacity must not be mated or unmated when live or under load.
- solid conductor:
- 0.25 4 mm / 22 12 AWG
- solid conductor push in termination:
- 0.75 4 mm / 18 12 AWG
- strip length:
- 10 12 mm / 0.39 0.47 inch
- weight:
- 29.595 g
- width:
- 46.8 mm / 1.843 inch
- wiring direction:
- Front-entry wiring
