WAGO 2042-3869 relay module, 4-pack, SPST-NC, SPST-NO, 5A, 230V coil voltage
Wago
$368.80
Relay module; Nominal input voltage: 24
230 V AC/DC; 1 break and 1 make contact; Limiting continuous current: 5 A; Green status indicator; Module width: 20 mm.
The WAGO 2042 series replacement plug-in relay features a green LED and is a 2-pole (2P) electromechanical relay with control voltages ranging from 21.6 to 253V AC/DC. It supports nominal voltages of 24V, 120V, 220V, and 230V, with a tolerance of 0.9 to 1.1 times the control voltage. The relay includes one normally open (1NO/SPST-NO) and one normally closed (1NC/SPST-NC) contact, with a rated continuous current of 5A. It has push-in connections, plug-in mounting, and an IP20 protection rating. The contacts are made of Silver-Nickel (AgNi), and it is equivalent to model 20423869.
- bounce time typ:
- 4 ms
- contact material relay:
- AgNi
- country of origin sales organisation germany:
- DE
- depth:
- 52 mm / 2.047 inch
- dielectric strength channel channel ac 1 min:
- 1.5 kVrms
- dielectric strength control load circuit ac 1 min:
- 3 kVrms
- dielectric strength open contact ac 1 min:
- 1 kVrms
- drop out time typ:
- 6 ms
- electrical life no resistive load 23 c:
- 100 x 103 switching operations
- fire load:
- 0.871 MJ
- flammability class per ul94:
- V0
- height:
- 77.7 mm / 3.059 inch
- height from the surface:
- 59.3 mm / 2.335 inch
- input voltage range:
- 10 %
- inrush current resistive max:
- (AC) 15 A / 4 s
- limiting continuous current:
- 0.208333333333333
- mechanical life:
- 10 x 106 switching operations
- mounting type:
- Pluggable module for TOPJOB« S Carrier Terminal Block
- nominal input current at un:
- 2.8 mA (230 V): 49.1 mA (24 V)
- nominal input voltage un:
- AC/DC 24 ª 230 V
- number of break switch off contacts:
- 1
- number of make switch on contacts:
- 1
- operating altitude max:
- 2000 m
- packaging type:
- Box
- pollution degree:
- 2
- processing temperature:
- -25 ª +50 C
- protection type:
- IP20
- pull in time typ:
- 8 ms
- rated voltage:
- 250 V
- recommended minimum load:
- 12 V / 10 mA
- standards specifications:
- EN 61010-2-201 || EN 61373 || EN 50121-3-2
- status indicator:
- Green LED
- surrounding air temperature operation at un:
- -40 ª 70 C
- surrounding air temperature storage:
- -40 ª 85 C
- switching power resistive max:
- AC 1250 VA: DC (see load limit curve)
- switching voltage max:
- AC 250 V
- weight:
- 39.200 g
- width:
- 20.7 mm / 0.815 inch
