WAGO 2052-323 2-conductor miniature through tb with operating slots carrier unit 2.5 mm², red

The WAGO 2052 TOPJOB S series is a red, feed-through miniature center terminal block with one deck/level, featuring side and center marking slots. It is suitable for Ex e II applications and includes a test port. The terminal block supports one feed-through pole (1P) and accommodates two wires (1 push-in + 1 push-in) with a nominal cross-section of 2.5mm², suitable for wire sizes ranging from 0.25mm² to 4mm² or #22AWG to #12AWG. It has a rated current of 24A or 32A and utilizes Push-in CAGE CLAMP spring connections, equivalent to model 2052323.
