Wago

WAGO 206-1125

(No reviews yet) Write a Review

Write a Review

Wago

WAGO 206-1125

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

206-1125

UPC:

MPN:

2016-1307

Condition:

New

actuation type:

Push-in || Operating tool

color:

Green-yellow

connectable conductor materials:

Copper

connection technology:

Push-in CAGE CLAMP

country of origin sales organisation germany:

DE

depth from upper edge of din rail:

36.9 mm / 1.453 inch

design:

Horizontal type

fine stranded conductor:

0.5 25 mm / 20 4 AWG

fine stranded conductor with ferrule push in termination:

6 16 mm / 10 6 AWG

fine stranded conductor with insulated ferrule:

0.5 16 mm / 20 6 AWG

fire load:

0.456 MJ

flammability class per ul94:

V0

height:

91.8 mm / 3.622 inch

insulation material:

Polyamide (PA66)

marking level:

Center/side marking

mounting type:

DIN-35 rail

nominal cross section:

16 mm

note conductor cross section:

Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.

packaging type:

Box

ratings per:

IEC/EN 60947-7-2

safety information 1:

15 mm high DIN-35 rails shall be used for a current load higher than 76 A!

solid conductor:

0.5 16 mm / 20 6 AWG

solid conductor push in termination:

6 16 mm / 14 6 AWG

strip length:

18 20 mm / 0.71 0.79 inch

weight:

46.231 g

width:

12 mm / 0.472 inch

wiring direction:

Front-entry wiring
