WAGO 2060-953/028-000 Board-to-Board Link; Pin spacing 4 mm; 3-pole; Length: 28 mm; white
Wago
$0.78
Board-to-Board Link; Pin spacing 4 mm; 3-pole; Length: 28 mm; white.
The WAGO component equivalent to 2060953028000 is a specific part used in electrical and automation systems. It is designed to provide reliable and efficient connectivity solutions, ensuring secure and stable connections in various applications. This component is known for its high quality, durability, and compatibility with other WAGO products, making it a preferred choice for professionals in the industry.
- color:
- White
- contact material:
- Copper alloy
- contact plating:
- Silver-plated
- country of origin sales organisation germany:
- CN
- depth:
- 28 mm / 1.102 inch
- fire load:
- 0.000 MJ
- flammability class per ul94:
- V0
- height:
- 2.6 mm / 0.102 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +105 C
- material group:
- I
- mating cycles max:
- 10
- nominal voltage ii 2:
- 320 V
- nominal voltage iii 3:
- 63 V
- number of mating cycles:
- Max. 10 connections/disconnections
- packaging type:
- Box
- pin spacing:
- 4 mm / 0.157 inch
- pole no:
- 3
- rated current:
- 0.375
- rated current ul 1977:
- 0.375
- rated surge voltage ii 2:
- 2.5 kV
- rated surge voltage iii 2:
- 2.5 kV
- rated surge voltage iii 3:
- 2.5 kV
- rated voltage iii 2:
- 160 V
- rated voltage ul 1977:
- 250 V
- ratings per:
- IEC/EN 60664-1
- safety information 1:
- NOTE: Only suitable for 2060-45x, not for 2060-40x.
- suitable:
- For SMD PCB terminal blocks (2060 Series)
- weight:
- 0.690 g
- width:
- 11.4 mm / 0.449 inch
