WAGO 209-995 Pack of 5
Wago
$36.50
WSB marking card; as card; MARKED; 12, A1, A2, 24, 11, 14, 21, 22); not stretchable; Vertical marking; snap-on type; white.
The labeled WSB marking card from WAGO (209 series) is designed for vertical marking and includes labels with the following markings: "12", "A1", "A2", "24", "11", "14", "21", "22", and two blank labels. The card is white in color, features snap-on mounting, and contains 100 labels per card, arranged in 10 strips with 10 labels per strip. It is compatible with 5mm-wide terminal blocks and is equivalent to the 209995 model.
- color:
- White
- country of origin sales organisation germany:
- DE
- fire load:
- 0.234 MJ
- marker strip width:
- 5 mm
- marker width:
- 5 mm
- marking:
- 12, A1, A2, 24, 11, 14, 21, 22, , :
- marking color:
- Black
- marking direction:
- Vertical marking
- marking number:
- 10
- marking type:
- Symbol
- packaging type:
- Box
- pre assembly:
- 10 strips with 10 markers per card
- representation of the imprint:
- Consecutive symbols each strip
- smear resistance:
- EN 60998-1:2004
- uv resistance:
- EN 60068-2-5:2010 Procedure B
- weight:
- 7.800 g
