WAGO 2091-1728/200-000 Solder Pin Strip, 8-Pole, 3.5mm Pitch, 400 Pieces
Wago
$652.00
THR male header; 1.0 mm solder pin; angled; Pin spacing 3.5 mm; 8-pole; black.
The WAGO component equivalent to 20911728200000 is a specific part or module used in electrical and automation systems, known for its reliability and efficiency in various applications. This component is designed to meet specific technical requirements and standards, ensuring compatibility and optimal performance within WAGO's extensive range of products. It is commonly utilized in industrial automation, control systems, and other related fields where precise and dependable electrical connections are crucial.
- color:
- Black
- connector connection type:
- For PCB
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Tin-plated
- contact type pluggable connector:
- Male connector/plug
- country of origin sales organisation germany:
- CN
- depth:
- 10.2 mm / 0.402 inch
- fire load:
- 0.000 MJ
- flammability class per ul94:
- V0
- height:
- 5.9 mm / 0.232 inch
- height from the surface:
- 3.5 mm / 0.138 inch
- insulation material:
- Polyphthalamide (PPA GF)
- legend ratings:
- (III / 2) « Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 ª +100 C
- locking of plug in connection:
- Without
- material group:
- I
- mating direction to the pcb:
- 0
- mismating protection:
- No
- nominal voltage ii 2:
- 320 V
- nominal voltage iii 3:
- 160 V
- packaging type:
- Bag
- pcb contact:
- THR
- pin spacing:
- 3.5 mm / 0.138 inch
- plated through hole diameter thr:
- 1.2 (+0.1) mm
- pole no:
- 8
- rated current:
- 0.416666666666667
- rated surge voltage ii 2:
- 2.5 kV
- rated surge voltage iii 2:
- 2.5 kV
- rated surge voltage iii 3:
- 2.5 kV
- rated voltage iii 2:
- 160 V
- ratings per:
- IEC/EN 60664-1
- safety information 1:
- The picoMAX« Pluggable Connection System includes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load. The circuit design should ens
- solder pin diameter:
- 1 mm
- solder pin length:
- 2.4 mm
- weight:
- 1.020 g
- width:
- 29.7 mm / 1.169 inch
