(III / 2) Overvoltage category III / Pollution degree 2
limit temperature range:
-60 +100 C
locking of plug in connection:
Without
material group:
I
mating direction to the pcb:
0
mismating protection:
No
nominal voltage ii 2:
320 V
nominal voltage iii 3:
160 V
packaging type:
Bag
pcb contact:
THR
pin spacing:
3.5 mm / 0.138 inch
plated through hole diameter thr:
1.2 (+0.1) mm
pole no:
10
rated current:
0.416666666666667
rated surge voltage ii 2:
2.5 kV
rated surge voltage iii 2:
2.5 kV
rated surge voltage iii 3:
2.5 kV
rated voltage iii 2:
160 V
ratings per:
IEC/EN 60664-1
safety information 1:
The picoMAX Pluggable Connection System includes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load. The circuit design should en
