WAGO 2091-1732 12-Pole Solder Pin Header, 1.0 mm Pitch, 10A, 160V, 300 Pieces
Wago
$729.00
THT male header; 1.0 mm solder pin; angled; Pin spacing 3.5 mm; 12-pole; black.
The WAGO component equivalent to 20911732 is a specific part or model within the WAGO product line, which is known for its high-quality electrical interconnection and automation solutions. This component is likely used in various industrial and commercial applications, providing reliable performance and compatibility with other WAGO products. The exact specifications and features of this component would align with the standards and requirements typical of WAGO's offerings, ensuring it meets the needs of its intended use cases.
- color:
- Black
- connector connection type:
- For PCB
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Tin-plated
- contact type pluggable connector:
- Male connector/plug
- country of origin sales organisation germany:
- CN
- depth:
- 10.2 mm / 0.402 inch
- drilled hole diameter with tolerance:
- 1.2 (+0.1) mm
- fire load:
- 0.000 MJ
- flammability class per ul94:
- V0
- height:
- 7.1 mm / 0.28 inch
- height from the surface:
- 3.5 mm / 0.138 inch
- insulation material:
- Polyphthalamide (PPA GF)
- legend ratings:
- (III / 2) « Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 ª +100 C
- locking of plug in connection:
- Without
- material group:
- I
- mating direction to the pcb:
- 0
- mismating protection:
- No
- nominal voltage ii 2:
- 320 V
- nominal voltage iii 3:
- 160 V
- packaging type:
- Bag
- pcb contact:
- THT
- pin spacing:
- 3.5 mm / 0.138 inch
- pole no:
- 12
- rated current:
- 0.416666666666667
- rated surge voltage ii 2:
- 2.5 kV
- rated surge voltage iii 2:
- 2.5 kV
- rated surge voltage iii 3:
- 2.5 kV
- rated voltage iii 2:
- 160 V
- ratings per:
- IEC/EN 60664-1
- safety information 1:
- The picoMAX« Pluggable Connection System includes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load. The circuit design should ens
- solder pin diameter:
- 1 mm
- solder pin length:
- 3.6 mm
- weight:
- 1.640 g
- width:
- 43.7 mm / 1.720 inch
