WAGO 2092-1403 THT male header; 1.4 mm Ø solder pin; straight; Pin spacing 5 mm; 3-pole; light gray
Wago
$0.87
THT male header; 1.4 mm solder pin; straight; Pin spacing 5 mm; 3-pole; light gray.
The WAGO component equivalent to 20921403 is a specific part or module used in electrical and automation systems. It is designed to provide reliable and efficient connectivity solutions, ensuring seamless integration and communication within various industrial applications. This component is known for its high quality, durability, and compatibility with other WAGO products, making it a preferred choice for professionals in the field.
- actuator connection:
- 2 x (1-wire)
- color:
- Light gray
- conformity marking:
- CE
- connection technology inputs outputs:
- 8 x CAGE CLAMP
- connection type 1:
- Inputs/outputs
- contact material:
- Ag alloy
- country of origin sales organisation germany:
- DE
- depth:
- 67.8 mm / 2.669 inch
- depth from upper edge of din rail:
- 60.6 mm / 2.386 inch
- drop out time max:
- 4 ms
- electrical switching operations min at max resistive load:
- 10 x 105
- emc emission of interference:
- Per EN 61000-6-4, marine applications
- emc immunity to interference:
- Per EN 61000-6-2, marine applications
- exposure to pollutants:
- Per IEC 60068-2-42 and IEC 60068-2-43
- fine stranded conductor:
- 0.08 2.5 mm / 28 14 AWG
- fire load:
- 0.880 MJ
- height:
- 100 mm / 3.937 inch
- housing material:
- Polycarbonate: polyamide 6.6
- indicators:
- LED (A, E) green: Status relay 1, relay 2
- isolation:
- 1500 V (system/field)
- load type of switching frequency:
- Nominal load
- mechanical switching operations min at max resistive load:
- 5 x 106
- mounting position:
- Horizontal (standing/lying): vertical
- mounting type:
- DIN-35 rail
- number of digital outputs:
- 2
- operating altitude:
- 0 2000 m
- output characteristic:
- Potential-free
- output circuit design:
- 2 changeover contacts || Relays
- output internal data width max:
- 2 bits
- packaging type:
- Box
- permissible h2s contaminant concentration at a relative humidity 75:
- 10 ppm
- permissible so2 contaminant concentration at a relative humidity 75:
- 25 ppm
- pollution degree 5:
- 2 per IEC 61131-2
- power consumption 5 v system supply:
- 90 mA
- protection type:
- IP20
- pull in time max:
- 8 ms
- relative humidity without condensation:
- 0.95
- shock resistance:
- 15g per IEC 60068-2-27
- solid conductor:
- 0.08 2.5 mm / 28 14 AWG
- strip length:
- 8 9 mm / 0.31 0.35 inch
- supply voltage system:
- 5 VDC: via data contacts
- surrounding air temperature operation:
- 0 55 C
- surrounding air temperature storage:
- -40 85 C
- switching current max:
- 0.0416666666666667
- switching current min:
- 100 mA
- switching current note:
- 1 A at 250 VAC and 40 VDC: 0.15 A at 300 VDC
- switching frequency max:
- 0.1 Hz: Nominal load
- switching voltage max:
- 250 VAC, 300 VDC
- switching voltage min:
- 12 V
- total number of channels module:
- 2
- vibration resistance:
- 4g per IEC 60068-2-6
- weight:
- 52.363 g
- width:
- 12 mm / 0.472 inch
- wiring interface:
- Fixed
