WAGO 216-242 insulated ferrule sleeve for 0.75 mm² (18 AWG) wire, 16 mm length, gray, pack of 1000
Wago
$252.00
Ferrule; Sleeve for 0.75 mm² / 18 AWG; insulated; electro-tin plated; electrolytic copper; gastight crimped; acc. to DIN 46228, Part 4/09.90; gray.
The WAGO 216 series insulated ferrule sleeve is designed for a single 0.75mm² wire, featuring a gray color, a length of 12mm, a 2.8mm diameter insulated collar, and a 1.2mm ferrule. It is equivalent to the model 216242.
- color:
- Gray
- country of origin sales organisation germany:
- DE
- diameter:
- 3.3 mm
- diameter 1:
- 2.8 mm
- diameter 2:
- 1.2 mm
- fire load:
- 0.002 MJ
- length:
- 16 mm
- length 1:
- 10 mm
- main product function:
- Ferrule
- packaging type:
- Box
- sleeve cross section awg:
- 18 AWG
- sleeve for:
- 0.75 mm
- strip length:
- 12 mm / 0.47 inch
- suitable:
- 2001 2002 Series
- weight:
- 0.105 g
