Description
4-conductor through terminal block, with push-button 2.5 mm², brown.
View AllClose
The WAGO 2202 TOPJOB S series feed-through terminal block is a brown, single-deck unit with side and center marking slots, suitable for Ex e II applications. It features a test port and accommodates one feed-through pole with four wires (two push-in connections on each side) for a nominal cross-section of 2.5mm², supporting wire sizes from 0.25mm² to 4mm² or #22AWG to #12AWG. The terminal block is rated for currents of 24A and 32A and utilizes Push-in CAGE CLAMP spring connections. It is designed for mounting on a DIN-35 rail (35 x 15 / 35 x 7.5) with a width of 5.2mm, equivalent to model number 22021401000014.
