Distribution terminal block; with push-button; 1 x 6 mm² / 6 x 1.5 mm²; with integrated end plate; suitable for Ex e II applications; side and center marking; for DIN-rail 35 x 15 and 35 x 7.5; Push-in CAGE CLAMP; 6,00 mm²; gray.
The WAGO 2206 TOPJOB S series is a gray feed-through distribution terminal block with a single deck and built-in end plate, suitable for Ex e II applications. It features side and center marking slots, accommodates one feed-through pole and seven wires (one push-in and six push-in), and supports a nominal cross-section of 6mm² for wire sizes ranging from 0.5mm² to 10mm² (#20AWG to #8AWG). The terminal block is rated for currents of 41A and 57A, utilizes Push-in CAGE CLAMP spring connections, and mounts on a DIN-35 rail with dimensions of 35 x 15 or 35 x 7.5 mm, with a width of 9mm. It is equivalent to model 22068031.
- actuation type:
- Push-in || Push-button
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- color:
- Gray
- connectable conductor materials:
- Copper
- connection technology:
- Push-in CAGE CLAMP«
- connection technology 2:
- Push-in CAGE CLAMP«
- connection type 1:
- Input
- connection type 2:
- Output
- contact plating:
- Tin-plated
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 32.9 mm / 1.295 inch
- fine stranded conductor:
- 0.5 ª 10 mm / 20 ª 8 AWG
- fine stranded conductor 2:
- 0.25 ª 2.5 mm / 22 ª 14 AWG
- fine stranded conductor with ferrule push in termination:
- 2.5 ª 6 mm / 16 ª 10 AWG
- fine stranded conductor with ferrule push in termination 2:
- 0.75 ª 1.5 mm / 18 ª 16 AWG
- fine stranded conductor with insulated ferrule:
- 0.5 ª 6 mm / 20 ª 10 AWG
- fine stranded conductor with insulated ferrule 2:
- 0.25 ª 1.5 mm / 22 ª 16 AWG
- fire load:
- 0.307 MJ
- flammability class per ul94:
- V0
- height:
- 73.8 mm / 2.905 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) « Overvoltage category III / Pollution degree 3
- marking level:
- Center/side marking
- mounting type:
- DIN-35 rail
- nominal cross section:
- 6 mm
- nominal cross section 2:
- 1.5 :
- nominal voltage iii 3:
- 800 V
- note:
- Available December 2021
- note conductor cross section:
- Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
- number of connection points:
- 1
- number of connection points 2:
- 6
- rated current:
- 41 A
- rated current 2:
- 57 A
- rated current ex e ii:
- 36 A
- rated current ex e ii with jumper:
- 24 A
- rated surge voltage iii 3:
- 8 kV
- rated voltage en ex e ii:
- 550 V
- solid conductor:
- 0.5 ª 10 mm / 20 ª 8 AWG
- solid conductor 2:
- 0.25 ª 2.5 mm / 22 ª 14 AWG
- solid conductor push in termination:
- 2.5 ª 10 mm / 14 ª 8 AWG
- solid conductor push in termination 2:
- 0.75 ª 2.5 mm / 18 ª 14 AWG
- strip length:
- 13 ª 15 mm / 0.51 ª 0.59 inch
- strip length 2:
- 9 ª 11 mm / 0.35 ª 0.43 inch
- weight:
- 16.402 g
- width:
- 9 mm / 0.354 inch
- wiring direction:
- Front-entry wiring
