Wago 221-422/K000-0002 Green Range LEVER-NUTS 2-Conductor Splicing Connector, 24-12 AWG, Box of 100
Wago
$43.25
This Wago 221-422/K000-0002 Green Range LEVER-NUTS splicing connector is a 2-conductor, lever-actuated terminal for quick, tool-free splicing of solid, stranded, and fine-stranded conductors. It uses Wagos CAGE CLAMP technology in a transparent housing, allowing visual verification of conductor insertion and contact status. The connector supports conductor sizes from 0.24 mm² (2412 AWG) with a strip length of 11 mm, and is rated up to 32 A and 450 V per EN 60664 with a maximum ambient temperature of 85 °C (T85). Typical applications include distribution and control panels, building wiring, OEM equipment wiring, and other installations requiring compact, releasable splices, with available mounting carriers for standardized rail or panel mounting where required. The Green Range version uses more sustainable materials while retaining full compatibility and performance with the standard 221 Series connector system.
Documentation
- Technical Datasheet Wago 221-422 Green Range, 2-Conductor Splicing Connector
- https://www.wago.com/221-422
- Product Family / 221 Series Green Range Overview
- https://www.wago.com/global/wire-splicing-connectors/221-series-green-range
- Installation Instructions 221 Series Splicing Connectors with Levers
- https://www.wago.com/global/wire-splicing-connectors/221-series-installation
- 2D/3D CAD Data 221-422 Splicing Connector (Green Range, 2-Conductor)
- https://www.wago.com/3d-cad/221-422
