Wago 221-612 Compact 2-Conductor Lever Splicing Connector, 10 AWG, Transparent Housing
Wago
$0.55
Documentation
- Technical Datasheet Wago 221-612
https://www.wago.com/221-612
- Installation Instructions Wago 221 Series Compact Splicing Connectors
https://www.wago.com/installation-guide/221-series
- 3D CAD Data Wago 221-612
https://www.wago.com/cad/221-612
- Product Family Overview Wago 221 Series Compact Splicing Connectors
https://www.wago.com/wire-splicing-connectors/221-series
- actuation type:
- Lever
- actuator color:
- Orange
- ambient temperature operation:
- +85 ðC
- approvals per:
- UL 486C
- Color:
- Transparent
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP®
- CONTINUOUS OPERATING TEMPERATURE:
- 105 ðC
- COUNTRY OF ORIGIN VKORG GERMANY:
- CH
- COVER COLOR:
- Transparent
- CUSTOMS TARIFF NUMBER VKORG GERMANY:
- 85369010000
- DEPTH:
- 21.1 mm / 0.831 inches
- FINE STRANDED CONDUCTOR:
- 0.5 ⦠6 mmò / 20 ⦠10 AWG
- FIRE LOAD:
- 0.050 MJ
- FLAMMABILITY CLASS PER UL94:
- V2
- HEIGHT:
- 10.1 mm / 0.398 inches
- LEGEND RATINGS:
- (II / 2) â Overvoltage category II / Pollution degree 2
- MEASUREMENT ERROR DEVIATION MAX FROM THE UPPER RANGE VALUE:
- MEASUREMENT ERROR DEVIATION MAX OF THE UPPER RANGE VALUE 2=
- MISMATING PROTECTION:
- MOUNTING NOTE=
- NOMINAL CROSS SECTION:
- 6 mmò / 10 AWG
- NOMINAL VOLTAGE II 2:
- 450 V
- NOTE MATERIAL DATA:
- Information on material data can be found here
- PACKAGING TYPE:
- Box
- PRODUCT GROUP CODE:
- 7
- RATED CURRENT:
- 41 A
- RATED CURRENT UL USE GROUP C:
- 30 A
- RATED SURGE VOLTAGE II 2:
- 4 kV
- RATED VOLTAGE UL USE GROUP C:
- 600 V
- RATINGS PER:
- EN 60664
- SAFETY INFORMATION 1:
- In grounded power lines
- SOLID CONDUCTOR:
- 0.5 ⦠6 mmò / 20 ⦠10 AWG
- STRANDED CONDUCTOR:
- 0.5 ⦠6 mmò / 20 ⦠10 AWG
- STRIP LENGTH:
- 12 ⦠14 mm / 0.47 ⦠0.55 inches
- TEMPERATURE MARKING PER EN 60998:
- T85
- WEIGHT:
- 3.024 g
- WIDTH:
- 16 mm / 0.63 inches
- WIRING DIRECTION:
- Side-entry wiring
