WAGO 2216-1304 3-Conductor Through Terminal Block, 16 mm², Push-in CAGE CLAMP®, Blue
Wago
$9.02
TOPJOBS feedthrough terminal block with Push-buttons; rail mount; 3-conductor; 12 mm wide; blue.
The WAGO 2216 TOPJOB S series is a blue neutral-through terminal block designed for Ex e II / Ex I applications, featuring a single deck/level with button, side/lateral, and center marking slots. It includes a test port and supports a 16mm² nominal cross-section of the main feed-through conductor, accommodating wire sizes from 0.5mm² to 25mm² (#20AWG to #4AWG). The terminal block has a rated current of 76A/90A and utilizes Push-in CAGE CLAMP spring connections. It is mounted on a DIN-35 rail (35 x 15 / 35 x 7.5) with a 12mm width and is equivalent to model 22161304.
- actuation type:
- Push-in || Push-button || Operating tool
- approvals per:
- UL 1059
- color:
- Blue
- connectable conductor materials:
- Copper
- connection technology:
- Push-in CAGE CLAMP
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 37.1 mm / 1.461 inch
- design:
- Horizontal type
- fine stranded conductor:
- 0.5 25 mm / 20 4 AWG
- fine stranded conductor with ferrule push in termination:
- 6 16 mm / 10 6 AWG
- fine stranded conductor with insulated ferrule:
- 0.5 16 mm / 20 6 AWG
- fire load:
- 0.000 MJ
- flammability class per ul94:
- V0
- height:
- 91.8 mm / 3.622 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- marking level:
- Center/side marking
- mounting type:
- DIN-35 rail
- nominal cross section:
- 16 mm
- nominal voltage iii 3:
- 800 V
- note conductor cross section:
- Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
- packaging type:
- Box
- rated current:
- 76 A
- rated current 2:
- 90 A
- rated current csa use group b:
- 85 A
- rated current csa use group c:
- 85 A
- rated current ex e ii:
- 76 A
- rated current ex e ii with jumper:
- 65 A
- rated current ul use group b:
- 85 A
- rated current ul use group c:
- 85 A
- rated surge voltage iii 3:
- 8 kV
- rated voltage csa use group b:
- 600 V
- rated voltage csa use group c:
- 600 V
- rated voltage en ex e ii:
- 550 V
- rated voltage ul use group b:
- 600 V
- rated voltage ul use group c:
- 600 V
- ratings per:
- IEC/EN 60947-7-1
- safety information 1:
- 15 mm high DIN-35 rails shall be used for a current load higher than 76 A!
- solid conductor:
- 0.5 16 mm / 20 6 AWG
- solid conductor push in termination:
- 2.5 16 mm / 14 6 AWG
- strip length:
- 18 20 mm / 0.71 0.79 inch
- weight:
- 32.179 g
- width:
- 12 mm / 0.472 inch
- wiring direction:
- Front-entry wiring
