WAGO 231-302/026-000 1-conductor female plug; 2.5 mm²; Pin spacing 5.08 mm; 2-pole; 2,50 mm²; orange
Wago
$2.35
(No reviews yet)
Write a Review
Write a Review
Wago
WAGO 231-302/026-000 1-conductor female plug; 2.5 mm²; Pin spacing 5.08 mm; 2-pole; 2,50 mm²; orange
1-conductor female plug; 2.5 mm; Pin spacing 5.08 mm; 2-pole.
The WAGO component equivalent to 231302026000 is a specific type of electrical connector or terminal block used in various industrial and automation applications. This component is designed to provide reliable and secure connections for electrical wiring, ensuring efficient and safe operation of electrical systems. It is known for its high-quality construction, ease of use, and compatibility with a wide range of electrical devices and systems. The WAGO 231302026000 equivalent is commonly used in control panels, machinery, and other electrical installations where dependable connections are crucial.
- actuation type:
- Operating tool
- connectable conductor materials note:
- Terminating Aluminum ConductorsWAGO spring clamp terminal blocks are suitable for solid aluminum conductors up to 4 mm/12 AWG if WAGO Alu-Plus Contact Paste is used for termination.Alu-Plus Contact Paste Advantages:Automatically
- color:
- Gray/gray
- connectable conductor materials:
- Copper || Aluminum
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- CN
- depth from upper edge of din rail:
- 58.5 mm / 2.303 inch
- design:
- Horizontal type
- fine stranded conductor:
- 0.08 2.5 mm / 28 12 AWG
- fire load:
- 0.130 MJ
- flammability class per ul94:
- V0
- height:
- 74 mm / 2.913 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- marking level:
- Center marking
- mounting type:
- DIN-35 rail
- nominal voltage iii 3:
- 500 V
- note conductor cross section:
- 12 AWG: THHN, THWN
- packaging type:
- Box
- rated current:
- 20 A
- rated surge voltage iii 3:
- 6 kV
- ratings per:
- IEC/EN 60947-7-1
- solid conductor:
- 0.08 2.5 mm / 28 12 AWG
- strip length:
- 8 9 mm / 0.31 0.35 inch
- weight:
- 10.711 g
- width:
- 5 mm / 0.197 inch
- wiring direction:
- Front-entry wiring
