WAGO 243-722 Pack of 400
Wago
$95.20
MICRO PUSH WIRE PCB connector; 4-conductor; AWG 24 - 18 solid; can be assembled into connector strips via dovetail joints; blue.
The WAGO component equivalent to 243722 is a specific type of electrical connector or terminal block used for various wiring applications. It is designed to provide secure and reliable connections in electrical circuits, ensuring efficient conductivity and safety. This component is commonly used in industrial, commercial, and residential electrical installations, offering ease of use and durability. The equivalent model to 243722 maintains the same high standards of quality and performance, making it a trusted choice for professionals in the electrical industry.
- approvals per:
- UL 1059
- clamping spring material:
- Copper alloy
- color:
- Blue
- conductor connection direction to pcb:
- 0
- conductor diameter:
- 0.5 1 mm / 24 18 AWG
- connectable conductor materials:
- Copper
- connection technology:
- PUSH WIRE
- connector connection type:
- For PCB
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Tin-plated
- contact type pluggable connector:
- Female connector/socket
- country of origin sales organisation germany:
- DE
- depth:
- 10.5 mm / 0.413 inch
- drilled hole diameter with tolerance:
- 1.2 (-0.05 +0.05) mm
- fire load:
- 0.012 MJ
- flammability class per ul94:
- V0
- height:
- 10 mm / 0.394 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +105 C
- material group:
- I
- mating direction to the pcb:
- 90
- nominal voltage ii 2:
- 630 V
- nominal voltage iii 3:
- 250 V
- packaging type:
- Box
- pin spacing:
- 5.75 mm / 0.226 inch
- pole no:
- 1
- rated current:
- 0.25
- rated current csa use group b:
- 0.291666666666667
- rated current csa use group d:
- 0.291666666666667
- rated current ul use group b:
- 0.291666666666667
- rated current ul use group d:
- 0.291666666666667
- rated surge voltage ii 2:
- 4 kV
- rated surge voltage iii 2:
- 4 kV
- rated surge voltage iii 3:
- 4 kV
- rated voltage csa use group b:
- 150 V
- rated voltage csa use group d:
- 150 V
- rated voltage iii 2:
- 320 V
- rated voltage ul use group b:
- 150 V
- rated voltage ul use group d:
- 150 V
- ratings per:
- IEC/EN 60664-1
- solder pin diameter:
- 1 mm
- solder pin length:
- 4.5 mm
- solid conductor:
- 0.5 1 mm / 24 18 AWG
- strip length:
- 5 6 mm / 0.2 0.24 inch
- weight:
- 0.747 g
- width:
- 5.75 mm / 0.226 inch
