WAGO 250-424/000-006 PCB Terminal Block, 24-Pole, 2.5mm Pitch, Push-In CAGE CLAMP®, Blue, Pack of 15
Wago
$66.15
PCB terminal block; push-button; 0.5 mm²; Pin spacing 2.5 mm; 24-pole; Push-in CAGE CLAMP; 0,50 mm²; blue.
The WAGO component equivalent to 250424000006 is a specific part or module used in electrical and automation systems. It is designed to meet particular technical specifications and requirements, ensuring compatibility and functionality within WAGO's range of products. This component plays a crucial role in the efficient operation of electrical circuits and automation processes, providing reliable performance and integration capabilities.
- actuation type:
- Push-button
- approvals per:
- CSA
- clamping spring material:
- Copper alloy
- color:
- Blue
- conductor connection direction to pcb:
- 45
- conductor diameter:
- 0.4 0.8 mm / 24 20 AWG
- connection technology:
- Push-in CAGE CLAMP
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Tin-plated
- country of origin sales organisation germany:
- CH
- depth:
- 12 mm / 0.472 inch
- drilled hole diameter with tolerance:
- 1 (+0.1) mm
- fine stranded conductor:
- 0.2 0.5 mm / 24 20 AWG
- fire load:
- 0.090 MJ
- flammability class per ul94:
- V0
- height:
- 16.7 mm / 0.657 inch
- height from the surface:
- 13.1 mm / 0.516 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +105 C
- material group:
- I
- nominal voltage ii 2:
- 320 V
- nominal voltage iii 3:
- 160 V
- number of solder pins per potential:
- 1
- packaging type:
- Box
- pcb contact:
- THT
- pin spacing:
- 2.5 mm / 0.098 inch
- pole no:
- 24
- rated current:
- 0.166666666666667
- rated current csa use group b:
- 0.208333333333333
- rated current csa use group d:
- 0.208333333333333
- rated current ul use group b:
- 0.208333333333333
- rated current ul use group d:
- 0.208333333333333
- rated surge voltage ii 2:
- 2.5 kV
- rated surge voltage iii 2:
- 2.5 kV
- rated surge voltage iii 3:
- 2.5 kV
- rated voltage csa use group b:
- 300 V
- rated voltage csa use group d:
- 300 V
- rated voltage iii 2:
- 160 V
- rated voltage ul use group b:
- 300 V
- rated voltage ul use group d:
- 300 V
- ratings per:
- IEC/EN 60664-1
- solder pin arrangement:
- Over the entire terminal strip (staggered)
- solder pin dimensions:
- 0.4 x 0.75 mm
- solder pin length:
- 3.6 mm
- solid conductor:
- 0.14 0.5 mm / 24 20 AWG
- strip length:
- 8.5 9.5 mm / 0.33 0.37 inch
- weight:
- 8.232 g
- width:
- 61.5 mm / 2.421 inch
