WAGO 250-703 Double-Deck PCB Terminal Block, 6-Pole, Push-Button, 1.5 mm², 5 mm Pin Spacing, Agate Gray, Pack of 45
Wago
$88.65
Double-deck PCB terminal block; Push-button; 1.5 mm; Pin spacing 5 mm; 2 x 3-pole; Push-in CAGE CLAMP
- Space-saving, double-deck terminal strips with push-buttons
- Push-in termination of solid and ferruled conductors
- Termination/removal of fine-stranded conductors via push-buttons
- 45 conductor entry angle provides easy, space-saving wiring
The WAGO component equivalent to 250703 is a specific type of electrical connector or terminal block used in various industrial and automation applications. It is designed to provide reliable and secure connections for electrical wiring, ensuring efficient and safe operation of electrical systems. This component is known for its durability, ease of use, and compatibility with a wide range of electrical devices and systems, making it a popular choice among professionals in the field.
- actuation type:
- Push-button
- approvals per:
- UL 1059
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- color:
- Agate gray
- conductor connection direction to pcb:
- 45
- connection technology:
- Push-in CAGE CLAMP
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Tin-plated
- country of origin sales organisation germany:
- CH
- depth:
- 21.7 mm / 0.854 inch
- drilled hole diameter with tolerance:
- 1.2 (-0.1 +0.1) mm
- fine stranded conductor:
- 0.75 1.5 mm
- fine stranded conductor with insulated ferrule:
- 0.5 1 mm
- fine stranded conductor with uninsulated ferrule:
- 0.5 1 mm
- fire load:
- 0.251 MJ
- flammability class per ul94:
- V0
- height:
- 24.9 mm / 0.98 inch
- height from the surface:
- 20.9 mm / 0.823 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- nominal voltage ii 2:
- 630 V
- nominal voltage iii 3:
- 320 V
- number of solder pins per potential:
- 1
- packaging type:
- Box
- pcb contact:
- THT
- pin spacing:
- 5 mm / 0.197 inch
- pole no:
- 6
- rated current:
- 0.416666666666667
- rated current csa use group b:
- 0.416666666666667
- rated current csa use group d:
- 0.416666666666667
- rated current ul use group b:
- 0.416666666666667
- rated current ul use group d:
- 0.416666666666667
- rated surge voltage ii 2:
- 4 kV
- rated surge voltage iii 2:
- 4 kV
- rated surge voltage iii 3:
- 4 kV
- rated voltage csa use group b:
- 300 V
- rated voltage csa use group d:
- 300 V
- rated voltage iii 2:
- 320 V
- rated voltage ul use group b:
- 300 V
- rated voltage ul use group d:
- 300 V
- ratings per:
- IEC/EN 60664-1
- solder pin arrangement:
- Over the entire terminal strip (in-line)
- solder pin dimensions:
- 0.5 x 0.75 mm
- solder pin length:
- 4 mm
- solid conductor:
- 0.5 1.5 mm / 20 16 AWG
- strip length:
- 9 10 mm / 0.35 0.39 inch
- weight:
- 5.910 g
- width:
- 16.2 mm / 0.638 inch
