2-conductor terminal block; with fixing flange; for screw or similar mounting types; Fixing hole 3.2 mm with 209-123 mounting carrier for DIN 35 rail.
The WAGO 261 series feed-through ground/earthing terminal block features a single deck with side marking slots, is green-yellow in color, and supports one grounding/protective-earth connection for two wires using one clamp each. It accommodates wire sizes from 0.08mm² to 2.5mm² or #28AWG to #14AWG, utilizes CAGE CLAMP spring connections, and has a 3.2mm fixing hole for mounting. This terminal block is equivalent to model 261307.
- actuation type:
- Operating tool
- color:
- Green-yellow
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- CH
- depth:
- 28.1 mm / 1.106 inch
- design:
- Horizontal type
- fine stranded conductor:
- 0.08 2.5 mm / 28 14 AWG
- fire load:
- 0.042 MJ
- flammability class per ul94:
- V0
- height from the surface:
- 18.1 mm / 0.713 inch
- insulation material:
- Polyamide (PA66)
- marking level:
- Side marking
- mounting type:
- Mounting flange
- packaging type:
- Box
- solid conductor:
- 0.08 2.5 mm / 28 14 AWG
- strip length:
- 8 9 mm / 0.31 0.35 inch
- weight:
- 2.320 g
- width:
- 6 mm / 0.236 inch
- wiring direction:
- Side-entry wiring
