2-conductor terminal block; without push-buttons; suitable for Ex i applications; with snap-in mounting foot; 1-pole; for plate thickness 0.6 - 1.2 mm; Fixing hole 3.5 mm Ã; 2.5 mm²; CAGE CLAMP; 2,50 mm²; blue.
The WAGO 261 series neutral-through terminal block is a blue, single-deck component designed for Ex I applications, featuring snap-in mounting foot and side marking slots. It accommodates two wires (one clamp each) ranging from 0.08mm² to 2.5mm² or #28AWG to #14AWG, and supports a rated current of 24A. The terminal block uses CAGE CLAMP spring connections and can be mounted on a DIN rail or surface using an accessory snap-in foot, with a width of 6mm, equivalent to model 261314.
- actuation type:
- Operating tool
- color:
- Blue
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- CH
- depth:
- 28.1 mm / 1.106 inch
- design:
- Horizontal type
- fine stranded conductor:
- 0.08 2.5 mm / 28 14 AWG
- fire load:
- 0.042 MJ
- flammability class per ul94:
- V0
- height from the surface:
- 18.1 mm / 0.713 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- marking level:
- Side marking
- mounting type:
- Snap-in foot
- nominal voltage iii 3:
- 500 V
- packaging type:
- Box
- rated current:
- 24 A
- rated surge voltage iii 3:
- 6 kV
- solid conductor:
- 0.08 2.5 mm / 28 14 AWG
- strip length:
- 8 9 mm / 0.31 0.35 inch
- weight:
- 2.344 g
- width:
- 6 mm / 0.236 inch
- wiring direction:
- Side-entry wiring
