dielectric strength control load circuit ac 1 min:
5 kVrms
dielectric strength open contact ac 1 min:
1.25 kVrms
drop out time typ:
5 ms
electrical life no resistive load 23 c:
5 x 103 switching operations
fine stranded conductor:
0.34 2.5 mm / 22 14 AWG
fire load:
0.676 MJ
height:
86 mm / 3.386 inch
input voltage range:
-10 +20 %
inrush current resistive max:
(AC) 165 A / 0.02 s
limiting continuous current:
16 A
mechanical life:
5 x 106 switching operations
mounting type:
DIN-35 rail
nominal input current at un:
17 mA
nominal input voltage un:
DC 24 V
note:
Reinforced insulation between coil and contactsTo protect the relay coils and contacts, inductive loads must be dampened with an effective protection circuit.
number of make switch on contacts:
1
packaging type:
Box
pollution degree:
3
processing temperature:
-25 +50 C
protection type:
IP20
pull in time typ:
10 ms
rated surge voltage:
4 kV
rated voltage:
250 V
recommended minimum load:
12 V / 100 mA
safety information 1:
A separator plate (e.g., 209-191) must be used for voltages greater than 250 V between adjacent relay modules and for compliance with the reinforced insulation requirements.
