Mini-WSB marking card; as card; MARKED; L1, , L2, , L3, , N, , PE; not stretchable; Horizontal marking; snap-on type; white.
The Labeled Mini-WSB marking card by WAGO (264 series) is designed for horizontal marking and features labels marked with "L1," "L2," "L3," "N," and "PE," interspersed with blank labels. It is white in color, uses snap-on mounting, and includes 100 labels per card, arranged in 10 strips with 10 labels each. These labels are compatible with 5mm-wide terminal blocks.
- color:
- White
- country of origin sales organisation germany:
- DE
- fire load:
- 0.201 MJ
- marker strip width:
- 5 mm
- marker width:
- 5 mm
- marking:
- L1, , L2, , L3, , N, , , :
- marking color:
- Black
- marking direction:
- Horizontal marking
- marking number:
- 10
- marking type:
- Symbol
- packaging type:
- Box
- pre assembly:
- 10 strips with 10 markers per card
- representation of the imprint:
- Consecutive symbols each strip
- smear resistance:
- EN 60998-1:2004
- uv resistance:
- EN 60068-2-5:2010 Procedure B
- weight:
- 6.250 g
