WAGO 2706-107 PCB Terminal Block, 7-Pole, 6mm², Cage Clamp, 41A, 630V
Wago
$12.28
PCB terminal block; lever; 6 mm²; Pin spacing 7.5 mm; 7-pole; CAGE CLAMP; 6,00 mm²; gray.
The WAGO component equivalent to 2706107 is a specific type of electrical connector or terminal block used in various industrial and automation applications. It is designed to provide reliable and secure connections for electrical wiring, ensuring efficient and safe operation of electrical systems. This component is known for its high-quality construction, ease of use, and compatibility with a wide range of electrical devices and systems.
- actuation type:
- Lever
- approvals per:
- UL 1059
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- color:
- Gray
- conductor connection direction to pcb:
- 30
- connection technology:
- CAGE CLAMP
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Tin-plated
- country of origin sales organisation germany:
- PL
- depth:
- 26 mm / 1.024 inch
- drilled hole diameter with tolerance:
- 1.8 (+0.1) mm
- fine stranded conductor:
- 0.5 6 mm / 20 10 AWG
- fine stranded conductor with insulated ferrule:
- 0.5 6 mm
- fine stranded conductor with uninsulated ferrule:
- 0.5 6 mm
- fire load:
- 0.721 MJ
- flammability class per ul94:
- V0
- height:
- 30 mm / 1.181 inch
- height from the surface:
- 25.5 mm / 1.004 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +105 C
- material group:
- I
- nominal voltage ii 2:
- 1000 V
- nominal voltage iii 3:
- 500 V
- number of solder pins per potential:
- 2
- packaging type:
- Box
- pcb contact:
- THT
- pin spacing:
- 7.5 mm / 0.295 inch
- pole no:
- 7
- rated current:
- 41 A
- rated current ul use group b:
- 30 A
- rated current ul use group c:
- 30 A
- rated current ul use group d:
- 30 A
- rated surge voltage ii 2:
- 6 kV
- rated surge voltage iii 2:
- 6 kV
- rated surge voltage iii 3:
- 6 kV
- rated voltage iii 2:
- 630 V
- rated voltage ul use group b:
- 300 V
- rated voltage ul use group c:
- 150 V
- rated voltage ul use group d:
- 300 V
- ratings per:
- IEC/EN 60664-1
- solder pin arrangement:
- Over the entire terminal strip (in-line)
- solder pin dimensions:
- 1 x 1.4 mm
- solder pin length:
- 4.5 mm
- solid conductor:
- 0.5 6 mm / 20 10 AWG
- strip length:
- 11 12 mm / 0.43 0.47 inch
- weight:
- 36.407 g
- width:
- 52.5 mm / 2.067 inch
