WAGO 2706-260 PCB Terminal Block, 10-Pole, 10mm Pin Spacing
Wago
$19.29
PCB terminal block; operating lever; 6 mm; Pin spacing 10 mm; 10-pole; CAGE CLAMP; commoning option
- High-current terminal strips with lever-actuated CAGE CLAMP<sup></sup>
- Tool-free opening and closing fingers open/close levers
- Several clamping units can be held open simultaneously convenient for terminating multi-core cables
- Two solder pins per contact point for high mechanical stability
- Versions with commoning option for distributing potentials
The WAGO component equivalent to 2706260 is a specific type of electrical connector or terminal block used in various industrial and automation applications. It is designed to provide reliable and secure connections for electrical wiring, ensuring efficient and safe operation of electrical systems. This component is known for its high-quality construction, ease of use, and compatibility with a wide range of electrical devices and systems. It is commonly used in control panels, machinery, and other electrical installations where dependable connections are crucial.
- actuation type:
- Lever
- approvals per:
- UL 1059
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- color:
- Gray
- conductor connection direction to pcb:
- 30
- connection technology:
- CAGE CLAMP
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Tin-plated
- country of origin sales organisation germany:
- PL
- depth:
- 30 mm / 1.181 inch
- drilled hole diameter with tolerance:
- 1.8 (+0.1) mm
- fine stranded conductor:
- 0.5 6 mm / 20 10 AWG
- fine stranded conductor with insulated ferrule:
- 0.5 6 mm
- fine stranded conductor with uninsulated ferrule:
- 0.5 6 mm
- fire load:
- 1.385 MJ
- flammability class per ul94:
- V0
- height:
- 30 mm / 1.181 inch
- height from the surface:
- 25.5 mm / 1.004 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +105 C
- material group:
- I
- nominal voltage ii 2:
- 1000 V
- nominal voltage iii 3:
- 800 V
- number of solder pins per potential:
- 2
- packaging type:
- Box
- pcb contact:
- THT
- pin spacing:
- 10 mm / 0.394 inch
- pole no:
- 10
- rated current:
- 41 A
- rated current ul use group b:
- 30 A
- rated current ul use group c:
- 30 A
- rated current ul use group d:
- 0.208333333333333
- rated surge voltage ii 2:
- 8 kV
- rated surge voltage iii 2:
- 8 kV
- rated surge voltage iii 3:
- 8 kV
- rated voltage iii 2:
- 1000 V
- rated voltage ul use group b:
- 300 V
- rated voltage ul use group c:
- 300 V
- rated voltage ul use group d:
- 600 V
- ratings per:
- IEC/EN 60664-1
- solder pin arrangement:
- Over the entire terminal strip (in-line)
- solder pin dimensions:
- 1 x 1.4 mm
- solder pin length:
- 4.5 mm
- solid conductor:
- 0.5 6 mm / 20 10 AWG
- strip length:
- 11 12 mm / 0.43 0.47 inch
- weight:
- 67.647 g
- width:
- 97.5 mm / 3.839 inch
