WAGO 279-504 Double-Deck Terminal Block, Through/Through, Blue, 4 Positions, 18A, 500V
Wago
$4.77
Double-deck terminal block; Through/through terminal block; N/N; suitable for Ex i applications; for DIN-rail 35 x 15 and 35 x 7.5; 1.5 mm²; 1,50 mm²; blue.
The WAGO 279 series neutral-through terminal block is a double-deck terminal block with side marking slots, suitable for Ex I applications, and marked with "N/N." It features two neutral-through poles, each with two clamps, accommodating wire sizes from 0.08mm² to 1.5mm² or #28AWG to #16AWG, and supports a rated current of 18A. The terminal block uses CAGE CLAMP spring connections and is designed for mounting on a DIN-35 rail with dimensions of 35 x 15 or 35 x 7.5 mm, with a width of 4mm. It is equivalent to the model 279504 and comes in blue.
- actuation type:
- Operating tool
- color:
- Blue
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- CN
- depth from upper edge of din rail:
- 39 mm / 1.535 inch
- design:
- Horizontal type
- fine stranded conductor:
- 0.08 1.5 mm / 28 16 AWG
- fire load:
- 0.145 MJ
- flammability class per ul94:
- V0
- height:
- 85 mm / 3.346 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- marking level:
- Side marking
- mounting type:
- DIN-35 rail
- nominal voltage iii 3:
- 500 V
- packaging type:
- Box
- rated current:
- 18 A
- rated surge voltage iii 3:
- 6 kV
- ratings per:
- IEC/EN 60947-7-1
- solid conductor:
- 0.08 1.5 mm / 28 16 AWG
- strip length:
- 8 9 mm / 0.31 0.35 inch
- weight:
- 7.628 g
- width:
- 4 mm / 0.157 inch
- wiring direction:
- Front-entry wiring
