Wago

WAGO 280-104

(No reviews yet) Write a Review
SKU:
280-104
MPN:
280-104
Condition:
New
actuation type:
Operating tool
connectable conductor materials note:
Terminating Aluminum ConductorsWAGO spring clamp terminal blocks are suitable for solid aluminum conductors up to 4 mm/12 AWG if WAGO Alu-Plus Contact Paste is used for termination.Alu-Plus Contact Paste Advantages:Automatically
color:
Blue
connectable conductor materials:
Copper || Aluminum
connection technology:
CAGE CLAMP
country of origin sales organisation germany:
IN
depth from upper edge of din rail:
30.5 mm / 1.201 inch
design:
Horizontal type
fine stranded conductor:
0.08 2.5 mm / 28 12 AWG
fire load:
0.080 MJ
flammability class per ul94:
V0
height:
42.5 mm / 1.673 inch
insulation material:
Polyamide (PA66)
legend ratings:
(III / 3) Overvoltage category III / Pollution degree 3
marking level:
Side marking
mounting type:
DIN-35 rail
nominal voltage iii 3:
800 V
note conductor cross section:
12 AWG: THHN, THWN
packaging type:
Box
rated current:
24 A
rated surge voltage iii 3:
8 kV
ratings per:
IEC/EN 60947-7-1
solid conductor:
0.08 2.5 mm / 28 12 AWG
strip length:
8 9 mm / 0.31 0.35 inch
weight:
3.900 g
width:
5 mm / 0.197 inch
wiring direction:
Side-entry wiring
$2.04

Description

2-conductor through terminal block; 2.5 mm²; suitable for Ex i applications; lateral marker slots; for DIN-rail 35 x 15 and 35 x 7.5; CAGE CLAMP; 2,50 mm²; blue.

The WAGO 280 series neutral-through terminal block is a blue, single-deck component with side marking slots, designed for Ex I applications. It features a neutral-through pole (N) with two wire connections (1 clamp + 1 clamp) suitable for wire sizes ranging from 0.08mm² to 2.5mm² or #28AWG to #12AWG. The terminal block supports a rated current of 24A and utilizes CAGE CLAMP spring connections. It is mounted on a DIN-35 rail (35 x 15 / 35 x 7.5) with a 5mm width and is equivalent to model 280104.
