WAGO 281-652 Terminal Block, 4 Positions, 28 AWG, DIN Rail Mount
Wago
$4.48
4-conductor through terminal block; 4 mm²; center marking; for DIN-rail 35 x 15 and 35 x 7.5; CAGE CLAMP; 4,00 mm²; gray.
The WAGO 281 series feed-through terminal block is a gray, single-deck unit with a center marking slot, designed for one feed-through pole and accommodating four wires using two clamps on each side. It supports a nominal cross-section of 4mm² and is compatible with wire sizes ranging from 0.08mm² to 4mm² or #28AWG to #12AWG. The terminal block is rated for a current of 26A and features CAGE CLAMP spring connections. It is mounted on a DIN-35 rail with dimensions of 35 x 15 or 35 x 7.5mm and has a width of 6mm, equivalent to model 281652.
- color:
- White
- country of origin sales organisation germany:
- DE
- fire load:
- 0.215 MJ
- marker strip width:
- 4 4.2 mm
- marker width:
- 4 mm
- marking:
- 31 40
- marking color:
- Black
- marking direction:
- Horizontal marking
- marking number:
- 10
- marking type:
- Numbers
- packaging type:
- Box
- pre assembly:
- 10 strips with 10 markers per card
- representation of the imprint:
- Consecutive numbers per strip
- smear resistance:
- EN 60998-1:2004
- uv resistance:
- EN 60068-2-5:2010 Procedure B
- weight:
- 7.150 g
