WAGO 282-641
Wago
$72.00
Ground conductor disconnect terminal block; with test option; with orange disconnect link; 48 V; 6 mm²; CAGE CLAMP; 6,00 mm²; gray.
The WAGO 282 series ground conductor disconnect terminal block features a single deck with a knife-disconnect, an LED indicator for 48Vdc, a center marking slot, and a test point. It has one disconnect feed-through pole accommodating four wires with two clamps each, suitable for wire sizes ranging from 0.2mm² to 6mm² or #24AWG to #10AWG. The terminal block uses CAGE CLAMP spring connections and is designed for DIN-35 rail mounting with a 16mm width, equivalent to model 282641.
- actuation type:
- Operating tool
- color:
- Gray
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 37 mm / 1.457 inch
- design:
- Angled
- fine stranded conductor:
- 0.2 6 mm / 24 10 AWG
- fire load:
- 0.706 MJ
- flammability class per ul94:
- V0
- height:
- 85 mm / 3.346 inch
- marking level:
- Center marking
- mounting type:
- DIN-35 rail
- operation status indicator:
- 48 V
- packaging type:
- Box
- solid conductor:
- 0.2 6 mm / 24 10 AWG
- strip length:
- 12 13 mm / 0.47 0.51 inch
- weight:
- 40.700 g
- width:
- 16 mm / 0.63 inch
- wiring direction:
- Front-entry wiring
