WAGO 285-1175 Pack of 5

(No reviews yet) Write a Review

Write a Review

WAGO 285-1175 Pack of 5

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

285-1175

UPC:

MPN:

285-1175

Condition:

New

approvals per:

UL 1059

color:

Gray

connection technology:

CAGE CLAMP

country of origin sales organisation germany:

DE

design:

Angled

fine stranded conductor:

0.2 10 mm / 24 8 AWG

fine stranded conductor 2:

0.2 16 mm / 24 8 AWG

fire load:

0.320 MJ

insulation material:

Polyamide (PA66)

marking level:

Center marking

module width:

20 mm / 0.787 inch

nominal voltage iii 3:

1000 V

packaging type:

Box

rated current:

57 A

rated current csa use group b:

50 A

rated surge voltage iii 3:

8 kV

rated voltage csa use group b:

600 V

rated voltage csa use group c:

600 V

rated voltage ul use group b:

600 V

rated voltage ul use group c:

600 V

ratings per:

IEC/EN 60947-7-1

solid conductor:

0.2 10 mm / 24 8 AWG

solid conductor 2:

0.2 16 mm / 24 8 AWG

strip length:

12 13 mm / 0.47 0.51 inch

weight:

28.130 g

width:

20 mm / 0.787 inch

wiring direction:

Front-entry wiring
