Description
Relay module
View AllClose
Technical Data
- Nominal input voltage U<sub>N</sub>: DC 110 V
- Input voltage range: -30 +25 %
- Nominal input current at U<sub>N</sub>: 4.8 mA
- Number of changeover/switchover contacts: 1
- Contact material (relay): AgNi 0.15
- Limiting continuous current: 7 A
- Max. switching voltage: AC 250 V
- Max. switching power (resistive): AC 1750 VA
- Pull-in time (typ.): 8 ms
- Drop-out time (typ.): 6 ms
- Bounce time (typ): 4 ms
- Status indication: LED red
- Rated voltage: 250 V
- Rated impulse voltage: 4 kV
- Pollution degree: 2
- Dielectric strength, control/load circuit (AC, 1 min): 4 kVrms
- Dielectric strength open contact (AC, 1 min): 1 kVrms
- Protection class: IP20
Geometrical Data
- Width: 15 mm / 0.591 inch
- Height from upper-edge of DIN-35 rail: 82.5 mm / 3.248 inch
- Depth: 52 mm / 2.047 inch
Mechanical Data
- Type of mounting: Pluggable module for carrier terminal blocks
Material Data
- Color: gray
- Fire load: 0.000 MJ
- Weight: 23.100 g
Environmental Requirements
- Surrounding air (operating) temperature at U<sub>N</sub>: -25 70 C
- Surrounding air (storage) temperature: -25 70 C
- Processing temperature: -25 +50 C
Standards and specifications
- Standards/specifications: EN 60664-1
Commercial data
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4045454709105
- Customs Tariff No.: 85364900990
The WAGO 286 series replacement plug-in relay features a red LED and is a single-pole (1P) relay with a control voltage range of 77-137.5Vdc (nominal 110Vdc). It has a Single Pole Double Throw (SPDT) contact configuration and an electromechanical design, with a rated continuous current of 3A. The relay includes plug-in connections and is designed for plug-in mounting, with an IP20 protection rating. The contacts are made of Silver-Nickel (AgNi 0.15) material, and it is equivalent to the model 286307004000.
