WAGO 286-508 Relay Module, 230 VAC, 7 A, SPDT, 15 mm Width
Wago
$101.90
Relay module; Relay with 1 changeover contact (1u).
The WAGO 286 series replacement plug-in relay features a red LED and is a single-pole (1P) relay with a control voltage range of 207-253Vac (nominal 230Vac). It has a single pole double throw (SPDT) contact configuration, an electromechanical design, and a rated continuous current of 7A. The relay includes plug-in connections and mounting, has an IP20 protection rating, and uses Silver-Nickel (AgNi 0.15) contacts. It is equivalent to the model 286508.
- bounce time typ:
- 4 ms
- color:
- Gray
- contact material relay:
- AgNi 0.15
- country of origin sales organisation germany:
- DE
- depth:
- 52 mm / 2.047 inch
- dielectric strength control load circuit ac 1 min:
- 4 kVrms
- dielectric strength open contact ac 1 min:
- 1 kVrms
- drop out time typ:
- 6 ms
- electrical life no resistive load 23 c:
- 100 x 103 switching operations
- fire load:
- 0.324 MJ
- height from upper edge of din rail:
- 82.5 mm / 3.248 inch
- input voltage range:
- 10 %
- limiting continuous current:
- 0.291666666666667
- mechanical life:
- 30 x 106 switching operations
- mounting type:
- Pluggable module for receptacle terminal blocks
- nominal input current at un:
- 3.6 mA
- nominal input voltage un:
- AC 230 V
- number of changeover switchover contacts:
- 1
- operating altitude max:
- 2000 m
- packaging type:
- Box
- pollution degree:
- 2
- processing temperature:
- -25 +50 C
- protection type:
- IP20
- pull in time typ:
- 8 ms
- rated surge voltage:
- 4 kV
- rated voltage:
- 250 V
- relative humidity:
- 5 75 % (no condensation permissible)
- standards specifications:
- EN 60664-1
- status indicator:
- Red LED
- surrounding air temperature operation at un:
- -25 40 C
- surrounding air temperature storage:
- -25 70 C
- switching power resistive max:
- AC 1750 VA
- switching voltage max:
- AC 250 V
- weight:
- 30.643 g
- width:
- 15 mm / 0.591 inch
