WAGO 286-809 Component Module with 9 Diodes 1N4007, Common Anode, Gray
Wago
$57.12
CM-Dlight gray.
The component module features 9 diodes (1N4007) with a common anode, designed by WAGO (286 series), and supports control voltages of 250Vac/250Vdc. It is gray in color and utilizes CAGE CLAMP spring connections for secure and efficient wiring. The module is designed for plug-in mounting and is equivalent to the WAGO 286809 model.
- color:
- Gray
- country of origin sales organisation germany:
- DE
- depth:
- 52 mm / 2.047 inch
- fire load:
- 0.446 MJ
- height from upper edge of din rail:
- 82.5 mm / 3.25 inch
- housing design:
- Plug for carrier terminal blocks
- mounting type:
- Pluggable module for receptacle terminal blocks
- note:
- Max. admissible current per the manufacters data sheet. With all diodes loaded, the continuous current must be reduced.
- operating altitude max:
- 2000 m
- operating voltage:
- ¤ AC/DC 250 V
- packaging type:
- Box
- peak reverse voltage:
- 1000 V
- pollution degree:
- 2
- rated surge voltage:
- 4 kV
- rated voltage:
- 250 V
- rectified current for each diode resistive:
- 1 A || 1 A
- relative humidity:
- 5 95 % (no condensation permissible)
- surrounding air temperature operation:
- -25 40 C
- weight:
- 28.280 g
- width:
- 25 mm / 0.984 inch
