Technical Data
- Nominal input voltage U<sub>N</sub>: AC/DC 24 V
- Input voltage range: 10 %
- Nominal input current at U<sub>N</sub>: 21.8 mA
- Number of changeover/switchover contacts: 1
- Contact material (relay): AgNi 90/10
- Limiting continuous current: 6 A
- Max. make current (resistive): (AC) 16 A / 4 s
- Max. switching voltage: AC 250 V
- Max. switching power (resistive): AC 1500 VA
- Pull-in time (typ.): 9 ms
- Drop-out time (typ.): 3 ms
- Bounce time (typ): 2 ms
- Electrical life (N.O.; resistive load; 23 C): 100 x 10<sup>3 </sup>switching operations
- Mechanical life: 30 x 10<sup>6</sup> switching operations
- Rated voltage: 300 V
- Rated impulse voltage: 2.5 kV
- Pollution degree: 2
- Dielectric strength, control/load circuit (AC, 1 min): 4 kVrms
- Dielectric strength open contact (AC, 1 min): 1 kVrms
Connection Data
- Connection technology: CAGE CLAMP<sup></sup>
- Solid conductor: 0.08 2.5 mm / 28 12 AWG
- Fine-stranded conductor: 0.08 2.5 mm / 28 12 AWG
- Strip length: 5 6 mm / 0.2 0.24 inch
Geometrical Data
- Width: 20.5 mm / 0.807 inch
- Height from upper-edge of DIN-35 rail: 48 mm / 1.89 inch
- Depth: 85 mm / 3.346 inch
Mechanical Data
- Type of mounting: DIN-35 rail
Material Data
- Color: gray
- Fire load: 0.000 MJ
- Weight: 39.520 g
Environmental Requirements
- Surrounding air (operating) temperature at U<sub>N</sub>: -25 40 C
- Surrounding air (storage) temperature: -40 80 C
- Processing temperature: -25 +50 C
Standards and specifications
- Standards/specifications: EN 60664-1
Commercial data
- Packaging type: BOX
- Country of origin: CN
- GTIN: 4055143559119
- Customs Tariff No.: 85364900990
The WAGO 288 series plug-in relay assembly features a single-pole, single-pole double throw (SPDT) contact with a control voltage range of 21.6-26.4Vac or 21.6-26.4Vdc, nominally 24V. It has an electromechanical design, a rated current of 6A, and utilizes CAGE CLAMP connections. The relay is designed for DIN-35 rail mounting with a width of 20.5mm and has Silver-Nickel (AgNi 90/10) contacts. It is equivalent to model 288504.
- bounce time typ:
- 2 ms
- color:
- Gray
- connection technology:
- CAGE CLAMP
- contact material relay:
- AgNi 90/10
- country of origin sales organisation germany:
- CN
- depth from upper edge of din rail:
- 48 mm / 1.89 inch
- dielectric strength control load circuit ac 1 min:
- 4 kVrms
- dielectric strength open contact ac 1 min:
- 1 kVrms
- drop out time typ:
- 3 ms
- electrical life no resistive load 23 c:
- 100 x 103 switching operations
- fine stranded conductor:
- 0.08 2.5 mm / 28 12 AWG
- fire load:
- 0.651 MJ
- height:
- 85 mm / 3.346 inch
- input voltage range:
- 10 %
- inrush current resistive max:
- (AC) 16 A / 4 s
- limiting continuous current:
- 0.25
- mechanical life:
- 30 x 106 switching operations
- mounting type:
- DIN-35 rail
- nominal input current at un:
- 21.8 mA
- nominal input voltage un:
- AC/DC 24 V
- number of changeover switchover contacts:
- 1
- packaging type:
- Box
- pollution degree:
- 2
- processing temperature:
- -25 +50 C
- pull in time typ:
- 9 ms
- rated surge voltage:
- 2.5 kV
- rated voltage:
- 300 V
- solid conductor:
- 0.08 2.5 mm / 28 12 AWG
- standards specifications:
- EN 60664-1
- strip length:
- 5 6 mm / 0.2 0.24 inch
- surrounding air temperature operation at un:
- -25 40 C
- surrounding air temperature storage:
- -40 80 C
- switching power resistive max:
- AC 1500 VA
- switching voltage max:
- AC 250 V
- weight:
- 39.520 g
- width:
- 20.5 mm / 0.807 inch
