WAGO 289-585
Wago
$69.79
Interface module; with D-subminiature male connector; 9-pole; for mating connectors with solder connection; with shield connection; Vertical mounting
Electrical Data
- Operating voltage: nbsp;AC 100 V; nbsp;DC 125 V
- Nominal current: 2 A
- Contact resistance (max.): 30 m
- Specialty functions: With shield connection
Safety and protection:
- Rated voltage: 100 V
- Rated impulse voltage: 0.8 kV
- Pollution degree: 2
- Protection class: IP20
Connection Data
- Connection type (1): System
- No. of poles: 9
- Pluggable connector: D-subminiature; male connector
- For mating connectors: With solder connection
- Mating direction: Vertical
- Connection type (2): Field
- No. of poles 2: 10
- Design 2: PCB terminal blocks, 2-row
- Connection technology 2: CAGE CLAMP<sup></sup>
- WAGO terminal 2: WAGO 236 Series
- Solid conductor (2): 0.08 2.5 mm / 28 12 AWG
- Fine-stranded conductor (2): 0.08 2.5 mm / 28 12 AWG
- Strip length (2): 5 6 mm / 0.2 0.24 inch
- Note (conductor cross-section): 12 AWG: THHN, THWN
- Performance level: 2 / 200 mating cycles
- Strain relief: Gewindebolzen UNC 4-40
Geometrical Data
- Width: 38.5 mm / 1.516 inch
- Height from upper-edge of DIN-35 rail: 34 mm / 1.339 inch
- Depth: 85 mm / 3.346 inch
Mechanical Data
- Type of mounting: DIN-35 rail
- Housing design: Mounting carrier
Material Data
- Contact material (pluggable connector): Au over Ni
- Fire load: 0.000 MJ
- Weight: 47.490 g
Environmental Requirements
- Surrounding air (operating) temperature: -20 50 C
- Surrounding air (storage) temperature: -40 70 C
- Relative humidity: nbsp;85% (non condensing)
Standards and specifications
- Standards/specifications: UL 840
Commercial data
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4045454367152
- Customs Tariff No.: 85369010000
The WAGO 289 series interface module features a shielded connection in a mounting carrier, with a 9-pin D-sub male connector for system connections and a 2-row spring CAGE CLAMP 10-pin for field connections accommodating 0.08 to 2.5mm² cables. It supports a rated current of 2A, is designed for DIN-35 rail mounting with a width of 38.5mm, and has an IP20 protection rating. The module operates in ambient temperatures ranging from -20°C to +50°C and is equivalent to model 289585.
