WAGO 704-4004 Interface Module for System Wiring
Wago
$2,540.00
IM-S, DIN 41651 M.
The WAGO 704 series digital inputs interface module features a 20-pole configuration with a DIN 41651 20-pin male connector for system connections and double-deck spring CAGE CLAMPs for field connections, accommodating cables from 0.08 to 2.5mm². It is designed for vertical connection and DIN-35 rail mounting with a width of 105mm. The module operates within an ambient temperature range of -20°C to +40°C and is equivalent to model 7044004.
- ambient temperature operation:
- -20 ¦ +40 °C
- circuit type:
- 2-wire connection
- compatible plc models:
- Omron CJ1W || WAGO I/O System 750 || WAGO I/O System 753 || Rockwell Control Logix || Rockwell Compact Logix || Schneider Modicon Quantum || Schneider Modicon M340 || Schneider Twido || Schneider TSX || Schneider Modicon TM3 || GE Fanuc 9030 || Sieme
- compatible plc module types:
- 6ES7 313-5BE01-0AB0 || 6ES7 313-5BG04-0AB0 || 6ES7 313-6BE01-0AB0 || 6ES7 313-6BF03-0AB0 || 6ES7 313-6CE01-0AB0 || 6ES7 313-6CF03-0AB0 || 6ES7 314-6BF01-0AB0 || 6ES7 314-6BG03-0AB0 || 6ES7 314-6CG03-0AB0 || 6ES7 314-6CF01-0AB0 || 6ES7 321-1BH02-0AA0
- connection technology 2:
- CAGE CLAMP®
- connection technology 3:
- CAGE CLAMP®
- connection technology 4:
- CAGE CLAMP®
- connection type 1:
- System
- connection type 2:
- Field
- connection type 3:
- Field
- CONNECTION TYPE 4:
- Power supply
- CONNECTOR:
- DIN 41651 connector
- CONNECTOR 2:
- WAGO 736 Series
- CONNECTOR 3:
- WAGO 736 Series
- CONNECTOR 4:
- WAGO 736 Series
- COUNTRY OF ORIGIN VKORG GERMANY:
- FR
- CUSTOMS TARIFF NUMBER VKORG GERMANY:
- 85366990990
- DEPTH FROM UPPER EDGE OF DIN RAIL:
- 134 mm / 5.28 inches
- DESIGN 2:
- PCB terminal blocks (double-deck)
- DESIGN 3:
- PCB terminal blocks (double-deck)
- DESIGN 4:
- PCB terminal blocks (double-deck)
- FINE STRANDED CONDUCTOR 2:
- 0.08 ¦ 2.5 mm² / 28 ¦ 12 AWG
- FINE STRANDED CONDUCTOR 3:
- 0.08 ¦ 2.5 mm² / 28 ¦ 12 AWG
- FINE STRANDED CONDUCTOR 4:
- 0.08 ¦ 2.5 mm² / 28 ¦ 12 AWG
- FINE STRANDED CONDUCTOR WITH INSULATED FERRULE 2:
- 0.25 ¦ 1.5 mm²
- FINE STRANDED CONDUCTOR WITH INSULATED FERRULE 3:
- 0.25 ¦ 1.5 mm²
- FINE STRANDED CONDUCTOR WITH UNINSULATED FERRULE 2:
- 0.25 ¦ 2.5 mm²
- FINE STRANDED CONDUCTOR WITH UNINSULATED FERRULE 3:
- 0.25 ¦ 2.5 mm²
- FINE STRANDED CONDUCTOR WITH UNINSULATED FERRULE 4:
- 0.25 ¦ 2.5 mm²
- FIRE LOAD:
- 1.391 MJ
- HEIGHT:
- 50 mm / 1.97 inches
- INTERNAL FUSE:
- 0.0833333333333333
- MATING DIRECTION:
- Vertical
- MEASUREMENT ERROR DEVIATION MAX FROM THE UPPER RANGE VALUE:
- MEASUREMENT ERROR DEVIATION MAX OF THE UPPER RANGE VALUE 2=
- MISMATING PROTECTION:
- MOUNTING NOTE=
- MOUNTING TYPE:
- DIN-35 rail
- NOMINAL INPUT CURRENT AT UN:
- 14 mA
- NOMINAL INPUT VOLTAGE UN:
- AC/DC 24 V
- OPERATING ALTITUDE MAX:
- 2000 m
- PEAK OUTPUT CURRENT:
- 0.1 A
- POLE NUMBER:
- 20
- POLE NUMBER 2:
- 32
- POLE NUMBER 3:
- 4
- POLE NUMBER 4:
- 6
- POLLUTION DEGREE:
- 2
- PRODUCT GROUP CODE:
- 30
- RELATIVE HUMIDITY:
- ¤ 85% (non-condensing)
- SOLID CONDUCTOR 2:
- 0.08 ¦ 2.5 mm² / 28 ¦ 12 AWG
- SOLID CONDUCTOR 3:
- 0.08 ¦ 2.5 mm² / 28 ¦ 12 AWG
- SOLID CONDUCTOR 4:
- 0.08 ¦ 2.5 mm² / 28 ¦ 12 AWG
- STRIP LENGTH 2:
- 5 ¦ 6 mm / 0.2 ¦ 0.24 inches
- STRIP LENGTH 3:
- 5 ¦ 6 mm / 0.2 ¦ 0.24 inches
- STRIP LENGTH 4:
- 5 ¦ 6 mm / 0.2 ¦ 0.24 inches
- SURROUNDING AIR TEMPERATURE STORAGE:
- -40 ¦ +70 °C
- SWITCHING VOLTAGE MAX:
- DC 30 V
- WEIGHT:
- 280.000 g
- WIDTH:
- 105 mm / 4.13 inches
