WAGO 706-3140/300-200
Wago
$820.20
System cable; for Schneider Modicon Quantum; 2 x 16 digital inputs or outputs for higher voltages; Length: 2 m; Conductor cross-section: 0.34 mm².
The WAGO component equivalent to 7063140300200 is a specific part used in electrical and automation systems. It is designed to provide reliable and efficient connectivity solutions, ensuring secure and stable connections in various applications. This component is known for its high quality, durability, and compatibility with other WAGO products, making it a preferred choice for professionals in the industry.
- anschlusstyp 5:
- System
- cable length:
- 2 m
- cable type:
- LiYY
- color code:
- Per DIN VDE 47100
- compatible plc i o card types:
- 140 DAI 340 00 || 140 DAI 353 00 || 140 DAI 440 00 || 140 DAI 453 00 || 140 DAI 540 00 || 140 DAI 543 00 || 140 DAI 553 00 || 140 DAI 740 00 || 140 DAI 753 00 || 140 DAO 840 00 || 140 DAO 840 10 || 140 DRA 840 00
- compatible plc modules:
- Schneider Modicon Quantum
- connection type 1:
- System
- connection type 2:
- System
- connection type 3:
- System
- connection type 4:
- System
- connector 2:
- WAGO 231 Series
- connector 3:
- WAGO 231 Series
- connector 4:
- WAGO 231 Series
- connector 5:
- Schneider 140XTS00200
- country of origin sales organisation germany:
- FR
- current per wire max:
- 0.75 A
- fire load:
- 0.000 MJ
- inputs outputs:
- 2 x 16 digital inputs or outputs: for higher voltages
- note:
- If less than 3 channels used at the same time, the maximum current per wire 2 A and up to 5 A (amb. T 30 C) or 3.5 A (amb. T 50 C) on the power supply pins N/L. If more than 3 channels used at the same time, the maximum current per wire 0.75 A an
- operating voltage:
- ¤ AC/DC 250 V
- packaging type:
- Bag
- pluggable connectors:
- WAGO 231 Series
- pole number 1:
- 10
- pole number 2:
- 10
- pole number 3:
- 10
- pole number 4:
- 10
- pole number 5:
- 40
- surrounding air temperature operation:
- -20 50 C
- weight:
- 1408.000 g
- wire cross section:
- 0.34 mm
