WAGO 713-1102 1-conductor female connector, 2-row CAGE CLAMP, black
1-conductor female connector, 2-row; CAGE CLAMP; 1.5 mm²; Pin spacing 3.5 mm; 4-pole; 100% protected against mismating; 1,50 mm²; black.
The WAGO component equivalent to 7131102 is a specific type of electrical connector used for various applications. It is designed to provide reliable and secure connections in electrical systems, ensuring efficient conductivity and safety. This component is part of WAGO's extensive range of connectors, known for their high quality and durability, making them suitable for both industrial and commercial use. The 7131102 equivalent offers features such as easy installation, robust construction, and compatibility with various wire sizes, catering to the needs of professionals in the electrical and automation industries.
- actuation type:
- Operating tool
- anti rotation protection:
- Yes
- approvals per:
- UL 1059
- clamping spring material:
- Chrome-nickel spring steel (CrNi)
- color:
- Black
- conductor entry direction to mating direction:
- 0 °
- connection technology:
- CAGE CLAMP®
- CONNECTOR CONNECTION TYPE:
- For conductor
- CONTACT MATERIAL:
- Copper alloy
- CONTACT PLATING:
- Tin
- CONTACT TYPE PLUGGABLE CONNECTOR:
- Female connector/socket
- COUNTRY OF ORIGIN VKORG GERMANY:
- PL
- CUSTOMS TARIFF NUMBER VKORG GERMANY:
- 85366990990
- DEPTH:
- 16 mm / 0.63 inches
- FINE STRANDED CONDUCTOR:
- 0.08 ¢¦ 1.5 mm² / 28 ¢¦ 16 AWG
- FINE STRANDED CONDUCTOR WITH INSULATED FERRULE:
- 0.25 ¢¦ 1 mm²
- FINE STRANDED CONDUCTOR WITH UNINSULATED FERRULE:
- 0.25 ¢¦ 1 mm²
- FIRE LOAD:
- 0.042 MJ
- FLAMMABILITY CLASS PER UL94:
- V0
- HEIGHT:
- 18.8 mm / 0.74 inches
- INSULATION MATERIAL:
- Glass fiber-reinforced polyamide (PA66 GF)
- LEGEND RATINGS:
- (III / 2) ¢ Overvoltage category III / Pollution degree 2
- LIMIT TEMPERATURE RANGE:
- -60 ¢¦ +100 °C
- LOCKING OF PLUG IN CONNECTION:
- None
- MATERIAL GROUP:
- II
- MEASUREMENT ERROR DEVIATION MAX FROM THE UPPER RANGE VALUE:
- MEASUREMENT ERROR DEVIATION MAX OF THE UPPER RANGE VALUE 2=
- MISMATING PROTECTION:
- YesMOUNTING NOTE=
- NOMINAL VOLTAGE II 2:
- 250 V
- NOMINAL VOLTAGE III 3:
- 80 V
- NOTE MATERIAL DATA:
- Information on material data can be found here
- PIN SPACING:
- 3.5 mm / 0.138 inches
- PLUGGING WITHOUT LOSS OF PIN SPACING:
- No
- POLE NUMBER:
- 4
- PROCESSING TEMPERATURE:
- -35 ¢¦ +60 °C
- PRODUCT GROUP CODE:
- 3
- RATED CURRENT:
- 0.416666666666667
- RATED CURRENT CSA USE GROUP B:
- 0.416666666666667
- RATED CURRENT UL USE GROUP B:
- 0.416666666666667
- RATED CURRENT UL USE GROUP C:
- 0.416666666666667
- RATED IMPULSE VOLTAGE III 2:
- 2.5 kV
- RATED IMPULSE VOLTAGE III 3:
- 2.5 kV
- RATED SURGE VOLTAGE II 2:
- 2.5 kV
- RATED VOLTAGE CSA USE GROUP B:
- 300 V
- RATED VOLTAGE III 2:
- 160 V
- RATED VOLTAGE UL USE GROUP B:
- 300 V
- RATED VOLTAGE UL USE GROUP C:
- 50 V
- RATINGS PER:
- IEC/EN 60664-1
- SAFETY INFORMATION 1:
- The MCS ¢ MULTI CONNECTION SYSTEM includes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load.When used as intended, these conne
- SOLID CONDUCTOR:
- 0.08 ¢¦ 1.5 mm² / 28 ¢¦ 16 AWG
- STRIP LENGTH:
- 6 ¢¦ 7 mm / 0.24 ¢¦ 0.28 inches
- VARIABLE CODING:
- Yes
- VARIANTS:
- Other pole numbers || Gold-plated or partially gold-plated contact surfaces || Other versions (or variants) can be requested from WAGO Sales or configured at https://configurator.wago.com/.
- WEIGHT:
- 2.410 g
- WIDTH:
- 8.7 mm / 0.343 inches
