Wago 714-116

WAGO 714-116 1-conductor female plug; push-button; 1.5 mm²; Pin spacing 3.5 mm; 16-pole; 1,50 mm²; black

Wago
SKU:
714-116
Availability:
Contact us to confirm availability and lead times.
$15.73
Condition:
New
Current Stock:
Description
1-conductor female connector; push-button; 1.5 mm²; Pin spacing 3.5 mm; 16-pole; 1,50 mm²; black.

The WAGO component equivalent to 714116 is a specific type of electrical connector or terminal block used for various wiring applications. It is designed to provide secure and reliable connections in electrical circuits, ensuring efficient conductivity and safety. This component is commonly used in industrial, commercial, and residential electrical installations, offering ease of use and durability. The equivalent model to 714116 maintains the same high standards of performance and compatibility with existing systems, making it a suitable replacement or alternative for similar applications.

Additional Information
actuation type:
Push-button
approvals per:
UL 1059
clamping spring material:
Chrome nickel spring steel (CrNi)
color:
Black
conductor entry direction to mating direction:
0
connection technology:
Push-in CAGE CLAMP
connector connection type:
For conductor
contact material:
Copper alloy
contact plating:
Tin-plated
contact type pluggable connector:
Female connector/socket
country of origin sales organisation germany:
DE
depth:
23 mm / 0.906 inch
fine stranded conductor:
0.2 1.5 mm / 24 16 AWG
fine stranded conductor with insulated ferrule:
0.25 0.75 mm
fine stranded conductor with uninsulated ferrule:
0.25 1.5 mm
fire load:
0.000 MJ
flammability class per ul94:
V0
height:
7.8 mm / 0.307 inch
insulation material:
Polyamide (PA66)
legend ratings:
(III / 2) Overvoltage category III / Pollution degree 2
limit temperature range:
-60 +100 C
material group:
I
mismating protection:
No
nominal voltage ii 2:
320 V
nominal voltage iii 3:
160 V
packaging type:
Box
pin spacing:
3.5 mm / 0.138 inch
pole no:
16
rated current:
0.333333333333333
rated current ul use group b:
0.333333333333333
rated surge voltage ii 2:
2.5 kV
rated surge voltage iii 2:
2.5 kV
rated surge voltage iii 3:
2.5 kV
rated voltage iii 2:
160 V
rated voltage ul use group b:
150 V
ratings per:
IEC/EN 60664-1
safety information 1:
The MCS MULTI CONNECTION SYSTEM includes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load. The circuit design should ensure
solid conductor:
0.2 1.5 mm / 24 16 AWG
strip length:
9 10 mm / 0.35 0.39 inch
weight:
9.100 g
width:
56.7 mm / 2.232 inch
