Description
WAGO 726-652 Common potential matrix patchboard
View AllClose
Electrical Data
- Rated current: 76 A
- Rated current (2): 24 A
Connection Data
- Connection type (1): Side 1
- Connection technology: CAGE CLAMP<sup></sup>
- Number of connection points (connection type): 2
- Actuation type: Operating tool
- Connectable conductor materials: Copper
- Solid conductor: 0.2 16 mm / 24 6 AWG
- Fine-stranded conductor: 0.2 16 mm / 24 6 AWG
- Strip length: 16 17 mm / 0.63 0.67 inch
- Connection type (2): Side 2
- Number of connection points: 2
- Solid conductor (2): 0.08 2.5 mm / 28 14 AWG
- Fine-stranded conductor (2): 0.08 2.5 mm / 28 14 AWG
- Strip length (2): 8 10 mm / 0.31 0.39 inch
- Type of wiring: Front-entry wiring
Geometrical Data
- Width: 34.6 mm / 1.362 inch
- Height: 132 mm / 5.197 inch
- Depth: 80.7 mm / 3.177 inch
Mechanical Data
- Design: slimline
- Marking: 1 24
Material Data
- Color: dark gray
- Module color: gray
- Fire load: 0.000 MJ
- Weight: 259.458 g
Commercial data
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4055143628624
- Customs Tariff No.: 85369010000
The WAGO 726 series is a common potential matrix patchboard featuring a 2 x input module with a single deck/level and a built-in end plate, marked "1-24". It is a gray module with one feed-through pole (1P) that accommodates 48 wires (3 columns x 8 points x 2 wires each) suitable for wire sizes ranging from 0.2mm² to 16mm² or #24AWG to #6AWG. The patchboard supports a rated current of 76A/24A and utilizes Push-in CAGE CLAMP spring connections for surface mounting, equivalent to model 726652.
