4-level tb for matrix patching, with locking clips, white.
The WAGO 727 series feed-through terminal block is a quadruple-deck unit designed for matrix patching, featuring cover locking clips and a center marking slot with "3-2-1-0--0-1-2-3" markings. It is white and accommodates 4 feed-through poles, supporting 16 wires with 8 clamps on each side. Suitable for wire sizes ranging from 0.08mm² to 1.5mm² (#28AWG to #16AWG), it is rated for a current of 12A and utilizes CAGE CLAMP spring connections. The terminal block mounts on a DIN-35 rail with a width of 7.62mm and is equivalent to model 727221023000.
- actuation type:
- Operating tool
- color:
- White
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP«
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 62 mm / 2.441 inch
- design:
- Horizontal type
- fine stranded conductor:
- 0.08 ª 1.5 mm / 28 ª 16 AWG
- fire load:
- 0.576 MJ
- flammability class per ul94:
- V0
- height:
- 126 mm / 4.961 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) « Overvoltage category III / Pollution degree 3
- marking:
- 3-2-1-0--0-1-2-3
- marking level:
- Center marking
- mounting type:
- DIN-35 rail
- nominal voltage iii 3:
- 250 V
- packaging type:
- Box
- rated current:
- 0
- rated surge voltage iii 3:
- 4 kV
- solid conductor:
- 0.08 ª 1.5 mm / 28 ª 16 AWG
- strip length:
- 8 ª 10 mm / 0.31 ª 0.39 inch
- weight:
- 33.196 g
- width:
- 7.62 mm / 0.3 inch
- wiring direction:
- Front-entry wiring
