WAGO 734-435/001-000 THT double-deck male header, 10-pole, 3.81 mm pin spacing, angled, 1.0 x 1.0 mm solder pins, orange
Wago
$5.52
Double-deck male headers; Angled solder pin 1 x 1 mm; 5 x 2-pole; Pin spacing 3.81 mm / 0.15 in; 100% protected against mismating; Horizontal PCB mounting; with support.
The WAGO component equivalent to 734435001000 is a specific part used in electrical and electronic applications, known for its reliability and efficiency. This component is designed to provide secure and maintenance-free connections, often utilized in various industrial and automation settings. It ensures optimal performance and safety, making it a preferred choice for professionals seeking high-quality electrical components.
- approvals per:
- CSA
- color:
- Orange
- connector connection type:
- For PCB
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Tin-plated
- contact type pluggable connector:
- Male connector/plug
- country of origin sales organisation germany:
- DE
- depth:
- 21.8 mm / 0.858 inch
- drilled hole diameter with tolerance:
- 1.4 (+0.1) mm
- fire load:
- 0.117 MJ
- flammability class per ul94:
- V0
- height:
- 26.6 mm / 1.047 inch
- height from the surface:
- 23 mm / 0.906 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +100 C
- locking of plug in connection:
- Without
- material group:
- I
- mating direction to the pcb:
- 0
- mismating protection:
- Yes
- nominal voltage ii 2:
- 320 V
- nominal voltage iii 3:
- 160 V
- number of solder pins per potential:
- 1
- packaging type:
- Box
- pcb contact:
- THT
- pin spacing:
- 3.81 mm / 0.15 inch
- pole no:
- 10
- rated current:
- 0.416666666666667
- rated current csa use group b:
- 0.416666666666667
- rated current csa use group d:
- 0.416666666666667
- rated current ul use group b:
- 0.416666666666667
- rated current ul use group d:
- 0.416666666666667
- rated surge voltage ii 2:
- 2.5 kV
- rated surge voltage iii 2:
- 2.5 kV
- rated surge voltage iii 3:
- 2.5 kV
- rated voltage csa use group b:
- 300 V
- rated voltage csa use group d:
- 300 V
- rated voltage iii 2:
- 160 V
- rated voltage ul use group b:
- 300 V
- rated voltage ul use group d:
- 300 V
- ratings per:
- IEC/EN 60664-1
- safety information 1:
- The MCS MULTI CONNECTION SYSTEM includes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load. The circuit design should ensure
- solder pin arrangement:
- Over the entire male connector (in-line)
- solder pin dimensions:
- 1 x 1 mm
- solder pin length:
- 3.6 mm
- weight:
- 6.210 g
- width:
- 21.14 mm / 0.832 inch
