WAGO 739-124 PCB Terminal Block, 24-Pole, 5mm Pitch, CAGE CLAMP®
Wago
$10.51
PCB terminal block; 2.5 mm; Pin spacing 5 mm; 24-pole; CAGE CLAMPp>
- PCB terminal strips with screwdriver-actuated CAGE CLAMP<sup></sup>
- Vertical conductor entry and operating direction for space-saving positioning/grouping
The WAGO component equivalent to 739124 is a specific part or model within the WAGO product line, which is known for its high-quality electrical interconnection and automation solutions. This component is likely used in various applications requiring reliable and efficient electrical connections, such as in industrial automation, building technology, and other electrical engineering fields. The equivalent part ensures compatibility and performance consistency with the original 739124 model, maintaining WAGO's standards for safety, durability, and ease of use.
- actuation type:
- Operating tool
- approvals per:
- UL 1059
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- color:
- Gray
- conductor connection direction to pcb:
- 90
- connection technology:
- CAGE CLAMP
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Tin-plated
- country of origin sales organisation germany:
- CH
- depth:
- 14.3 mm / 0.563 inch
- drilled hole diameter with tolerance:
- 1.6 (+0.1) mm
- fine stranded conductor:
- 0.08 2.5 mm / 28 12 AWG
- fine stranded conductor with insulated ferrule:
- 0.25 1.5 mm
- fine stranded conductor with uninsulated ferrule:
- 0.25 2.5 mm
- fire load:
- 0.464 MJ
- flammability class per ul94:
- V0
- height:
- 19 mm / 0.748 inch
- height from the surface:
- 15.8 mm / 0.622 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +105 C
- material group:
- I
- nominal voltage ii 2:
- 630 V
- nominal voltage iii 3:
- 320 V
- note conductor cross section:
- 12 AWG: THHN, THWN
- number of solder pins per potential:
- 1
- packaging type:
- Box
- pcb contact:
- THT
- pin spacing:
- 5 mm / 0.197 inch
- pole no:
- 24
- rated current:
- 24 A
- rated current csa use group b:
- 0
- rated current csa use group d:
- 0.416666666666667
- rated current ul use group b:
- 20 A
- rated current ul use group d:
- 0.416666666666667
- rated surge voltage ii 2:
- 4 kV
- rated surge voltage iii 2:
- 4 kV
- rated surge voltage iii 3:
- 4 kV
- rated voltage csa use group b:
- 300 V
- rated voltage csa use group d:
- 300 V
- rated voltage iii 2:
- 320 V
- rated voltage ul use group b:
- 300 V
- rated voltage ul use group d:
- 300 V
- ratings per:
- IEC/EN 60664-1
- solder pin arrangement:
- Over the entire terminal strip (in-line)
- solder pin dimensions:
- 0.8 x 1.2 mm
- solder pin length:
- 3.2 mm
- solid conductor:
- 0.08 2.5 mm / 28 14 AWG
- strip length:
- 8 9 mm / 0.31 0.35 inch
- weight:
- 27.235 g
- width:
- 121.5 mm / 4.783 inch
