WAGO 739-333/001-000 PCB terminal block; 1.5 mm²; Pin spacing 3.81 mm; 3-pole; CAGE CLAMP; clamping collar; 1,50 mm²; orange
PCB terminal block; 1.5 mm²; Pin spacing 3.81 mm; 3-pole; CAGE CLAMP; clamping collar; 1,50 mm²; orange.
The WAGO component equivalent to 739333001000 is a specific part used in electrical and electronic applications, known for its reliability and efficiency. This component is designed to meet the same specifications and performance standards as the original part, ensuring compatibility and functionality in various systems. It is commonly used in industrial automation, control systems, and other technical fields where precise and dependable components are essential.
- actuation type:
- Operating tool
- approvals per:
- UL 1059
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- color:
- Orange
- conductor connection direction to pcb:
- 90
- connection technology:
- CAGE CLAMP
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Tin-plated
- country of origin sales organisation germany:
- PL
- depth:
- 13.4 mm / 0.528 inch
- drilled hole diameter with tolerance:
- 1.1 (+0.1) mm
- fine stranded conductor:
- 0.08 1.5 mm / 28 14 AWG
- fine stranded conductor with insulated ferrule:
- 0.25 1 mm
- fine stranded conductor with uninsulated ferrule:
- 0.25 1.5 mm
- fire load:
- 0.067 MJ
- flammability class per ul94:
- V0
- height:
- 15.7 mm / 0.618 inch
- height from the surface:
- 12.3 mm / 0.484 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +105 C
- material group:
- I
- mounting type:
- Mounting flange || Panel mounting
- nominal voltage ii 2:
- 500 V
- nominal voltage iii 3:
- 200 V
- note conductor cross section:
- 14 AWG: THHN, THWN
- number of solder pins per potential:
- 1
- packaging type:
- Box
- pcb contact:
- THT
- pin spacing:
- 3.81 mm / 0.15 inch
- pole no:
- 3
- rated current:
- 17.5 A
- rated current ul use group b:
- 15 A
- rated current ul use group d:
- 0.416666666666667
- rated surge voltage ii 2:
- 4 kV
- rated surge voltage iii 2:
- 4 kV
- rated surge voltage iii 3:
- 4 kV
- rated voltage iii 2:
- 320 V
- rated voltage ul use group b:
- 300 V
- rated voltage ul use group d:
- 300 V
- ratings per:
- IEC/EN 60664-1
- solder pin arrangement:
- Over the entire terminal strip (in-line)
- solder pin dimensions:
- 0.6 x 0.8 mm
- solder pin length:
- 3.4 mm
- solid conductor:
- 0.08 1.5 mm / 28 14 AWG
- strip length:
- 5 6 mm / 0.2 0.24 inch
- weight:
- 3.015 g
- width:
- 26.23 mm / 1.033 inch
