WAGO 745-110 PCB Terminal Block, 10-Pole, 5mm Pitch, CAGE CLAMP®
Wago
$7.84
PCB terminal block; 4 mm²; Pin spacing 5 mm; 10-pole; CAGE CLAMP; commoning option; 4,00 mm²; gray.
The WAGO component equivalent to 745110 is a specific type of electrical connector or terminal block used for various wiring applications. It is designed to provide secure and reliable connections in electrical circuits, ensuring efficient conductivity and safety. This component is typically used in industrial, commercial, and residential electrical installations, offering features such as easy installation, durability, and compatibility with different wire sizes and types. The equivalent model to 745110 maintains the same high standards of performance and reliability, making it a suitable replacement or alternative for similar applications.
- actuation type:
- Operating tool
- approvals per:
- CSA
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- color:
- Gray
- conductor connection direction to pcb:
- 45
- connection technology:
- CAGE CLAMP
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Tin-plated
- country of origin sales organisation germany:
- PL
- depth:
- 22.9 mm / 0.902 inch
- drilled hole diameter with tolerance:
- 1.5 (+0.1) mm
- fine stranded conductor:
- 0.08 4 mm / 28 12 AWG
- fine stranded conductor with insulated ferrule:
- 0.25 2.5 mm
- fine stranded conductor with uninsulated ferrule:
- 0.25 2.5 mm
- fire load:
- 0.334 MJ
- flammability class per ul94:
- V0
- height:
- 23 mm / 0.906 inch
- height from the surface:
- 19 mm / 0.748 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +105 C
- material group:
- I
- nominal voltage ii 2:
- 630 V
- nominal voltage iii 3:
- 320 V
- number of solder pins per potential:
- 2
- packaging type:
- Box
- pcb contact:
- THT
- pin spacing:
- 5 mm / 0.197 inch
- pole no:
- 10
- rated current:
- 32 A
- rated current csa use group b:
- 20 A
- rated current csa use group d:
- 0.416666666666667
- rated current ul use group b:
- 20 A
- rated current ul use group d:
- 0.416666666666667
- rated surge voltage ii 2:
- 4 kV
- rated surge voltage iii 2:
- 4 kV
- rated surge voltage iii 3:
- 4 kV
- rated voltage csa use group b:
- 300 V
- rated voltage csa use group d:
- 300 V
- rated voltage iii 2:
- 320 V
- rated voltage ul use group b:
- 300 V
- rated voltage ul use group d:
- 300 V
- ratings per:
- IEC/EN 60664-1
- solder pin arrangement:
- Over the entire terminal strip (in-line)
- solder pin dimensions:
- 0.8 x 1.2 mm
- solder pin length:
- 4 mm
- solid conductor:
- 0.08 4 mm / 28 12 AWG
- strip length:
- 8 9 mm / 0.31 0.35 inch
- weight:
- 20.502 g
- width:
- 51.5 mm / 2.028 inch
