WAGO 745-362
Wago
$13.72
PCB terminal block; 6 mm; Pin spacing 10 mm; 12-pole; CAGE CLAMP; commoning option
- PCB terminal strips with screwdriver-actuated CAGE CLAMP<sup></sup>
- Versions with Ex approval
- Common and distribute potentials via comb-style jumper bars
- Double solder pins for high mechanical stability
- Custom color combinations
- Integrated testing tap
- Marker slot for Mini-WSB markers
The WAGO component equivalent to 745362 is a specific part used in electrical and automation systems. It is designed to provide reliable and efficient connectivity solutions, ensuring secure and maintenance-free connections. This component is typically used in various applications, including industrial automation, building technology, and process control. It is known for its high quality, durability, and ease of installation, making it a preferred choice for professionals in the field. The equivalent part number indicates that it meets the same specifications and performance standards as the original WAGO component.
- actuation type:
- Operating tool
- approvals per:
- UL 1059
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- color:
- Gray
- conductor connection direction to pcb:
- 45
- connection technology:
- CAGE CLAMP
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Tin-plated
- country of origin sales organisation germany:
- PL
- depth:
- 29.1 mm / 1.146 inch
- drilled hole diameter with tolerance:
- 1.8 (+0.1) mm
- fine stranded conductor:
- 0.2 6 mm / 24 10 AWG
- fine stranded conductor with insulated ferrule:
- 0.25 4 mm
- fine stranded conductor with uninsulated ferrule:
- 0.25 4 mm
- fire load:
- 1.106 MJ
- flammability class per ul94:
- V0
- height:
- 27.5 mm / 1.083 inch
- height from the surface:
- 23 mm / 0.906 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +105 C
- material group:
- I
- nominal voltage ii 2:
- 1000 V
- nominal voltage iii 3:
- 630 V
- number of solder pins per potential:
- 2
- packaging type:
- Box
- pcb contact:
- THT
- pin spacing:
- 10 mm / 0.394 inch
- pole no:
- 12
- rated current:
- 41 A
- rated current csa use group b:
- 30 A
- rated current csa use group c:
- 30 A
- rated current csa use group d:
- 0.416666666666667
- rated current ul use group b:
- 30 A
- rated current ul use group c:
- 30 A
- rated current ul use group d:
- 0.416666666666667
- rated surge voltage ii 2:
- 8 kV
- rated surge voltage iii 2:
- 8 kV
- rated surge voltage iii 3:
- 8 kV
- rated voltage csa use group b:
- 300 V
- rated voltage csa use group c:
- 150 V
- rated voltage csa use group d:
- 300 V
- rated voltage iii 2:
- 1000 V
- rated voltage ul use group b:
- 300 V
- rated voltage ul use group c:
- 150 V
- rated voltage ul use group d:
- 300 V
- ratings per:
- IEC/EN 60664-1
- solder pin arrangement:
- Over the entire terminal strip (in-line)
- solder pin dimensions:
- 1 x 1.4 mm
- solder pin length:
- 4.5 mm
- solid conductor:
- 0.2 6 mm / 24 10 AWG
- strip length:
- 11 12 mm / 0.43 0.47 inch
- weight:
- 64.991 g
- width:
- 119.1 mm / 4.689 inch
